Software configuration
The I
NTER
B
US
bus can be configured in 3 modes:
b
Auto mode: this mode does not require the use of any special configuration software
(
the I/O images are copied to %IW and %QW implicitly). It facilitates the wiring test.
b
PL7
V
IBY mode: this mode is used to define and download the configuration to
the module (explicit assignment of %IW, %QW). The CMD Tool software
(1)
is
required to generate the configuration text file.
b
CMD
V
IBY mode: reserved for configurations > 8 K words, and requires the use
of the CMD Tool software.
PMS message handling (which can be used on PCP devices) is managed via
standard OFs (Read-var, Write-var, etc.).
The catalogue file for integrating Schneider Electric devices in the CMD Tool
software is available on our website:
b
Address:
www.schneider-electric.comb
File to download: Schneider device catalog for CMD
References
I
NTER
B
US
bus communication modules
Description
No. of
modules per
processor
Communic.
profile
Services Reference
Weight
kg
I
NTER
B
US
module for
Premium PLC
See pages
1/10
and 1/19
Master/slave
0.5
Mbps
Generation 4
-
Cyclic
variable
exchanges
-
PMS
messaging
-
Management
of bus
operating
modes
TSX IBY 100
0.320
Conversion software
Description Use
Reference
Weight
kg
Symbol
conversion
software
For converting CMD symbols to PL7 symbols
TLX LIBS CNVF
–
I
NTER
B
US
bus connection components
Description Use
Length Reference
Weight
kg
IP 20
distributed I/O
Modicon STB network interface
module
–
STB NIB 2212
0.155
Momentum communication module –
170
INT 110 00
0.070
Remote bus
cables
–
100
m
TSX IBS CA 100
7.340
400
m
TSX IBS CA 400
24.020
Installation
remote bus
cables
Preformed cables for linking 2
communication modules
0.110
m
170
MCI 007 00
0.060
1
m
170
MCI 100 00
0.320
Connecting
cables
Connecting TSX IB
p
module to PC
(
with CMD Tool software)
6
m
990
NAA 263 20
–
15
m
990
NAA 263 50
–
Connectors
Sold in lots of 2
9-
way SUB-D for remote bus
cables
–
170
XTS 009 00
0.045
(1)
Contact your Phœnix Contact vendor.
Presentation:
page 5/122
Description:
page 5/122
Software configuration,
references
TSX IBY 100
STB NIB 2212
170
INT 110 00
