Presentation
Incomer
PD390388
Compact NSX630 4P
Fixed, front connection
Motor mechanism
Direct supply via cables
Distribution
Powerclip busbars
Outgoing devices
Multi 9 devices
Supply
80 AMulticlip
200 AMul iclip
Comb busbars
Cable running
Cable straps
Trunking
Connection
Terminal block + earth bar at
bottom of the switchboard
Enclosure
Cubicle, W = 650 mm, D = 400 mm
PD390389
PD390563
Examples of switchboard
configurations
