Presentation
PD391302
Incoming function
Connection via Canalis
See pageA-9
Distribution function
Linergy busbars in busbar compartment,
W = 150 mm
See page B-6
Horizontal busbars
See page B-4
Powerclip busbars
See page B-40
Device compartment, W = 650 mm
See page C-18
Connection compartment, W = 300 mm
See page C-18
Connection compartment, W = 400 mm
See page C-18
1
2
3
4
5
The functions of an electrical
switchboard
