Presentation
Incomer
PD390398
Compact NS1000 4P
Fixed, front connection
Toggle
Supply via Canalis
Distribution
Linergy busbars
Outgoing devices
Compact NSX250
Horizontal
Fixed, front connection
Toggle
Supply
Prefabricated connection
Connection
Transferred to cable compartment,
W = 300 mm
Compact NSX400
Horizontal
Fixed, front connection
Toggle
Supply
Prefabricated connection
Connection
Transferred to cable compartment,
W = 300 mm
Multi 9 devices
Supply
Comb busbars
Cable running
Cable straps
Trunking
Connection
Terminal block at bottom of cubicle
Motor protection devices
Supply
Comb busbars
Cable running
Cable straps
Trunking
Connection
Terminal block in the cable
compartment, W = 300 mm
Enclosure
Cubicle for devices
W = 800/650 mm
D = 400 mm
PD390399
Cable compartment
W = 300 mm
D = 400 mm
Examples of switchboard
configurations
30
