Presentation
Incomer
PD391298
Compact NSX1000 4P
Fixed, front connection
Toggle
Supply via cables
Distribution
Linergy busbars
Outgoing devices
Compact NSX250
Horizontal
Fixed, front connection
Toggle
Supply
Prefabricated connection
Connection
Transferred to cable compartment,
W = 300 mm
Compact NSX250
Vertical
Fixed, front connection
Toggle
Supply
Polypact distribu ion block
Connection
Direct via cables
Multi 9 devices
Supply
80 AMulticlip
200 AMul iclip
Comb busbars
Cable running
Cable straps
Trunking
Connection
Terminal block in the cable
compartment, W = 300 mm
Enclosure
Cubicle for devices
W = 800 mm
D = 400 mm
Cable compartment
W = 300 mm
D = 400 mm
PD391172
PD390382
Fixed Compact NS1000, front connected with
cables.
Prefabricated connection between an
incoming device and Linergy busbars.
PD390383
PD395097
Prefabricated connection between Linergy
busbars and an NS250.
Connection transfer assembly for connection
in a cable compartment.
