TECHNICAL INFORMATION
Technical information
Cable capacity chart
Compartment 1
Systems 130 & 170
Compartment 2
Systems 130 & 170
Compartment 3
Systems 130 & 170
No box Withbox No box Withbox No box Withbox
PVC power cable 1.5mm
2
stranded copper
System 130
89
–
–
40
89
–
System 170
158
–
–
43
158
–
PVC power cable 2.5mm
2
stranded copper
System 130
60
–
–
27
60
–
System 170
106
–
–
29
106
–
PVC power cable 4.0mm
2
stranded copper
System 130
43
–
–
19
43
–
System 170
76
–
–
21
76
–
Data cable: Ø5.5mm
System 130
30
–
–
13
30
–
System 170
53
–
–
14
53
–
Data cable: Ø6.0mm
System 130
25
–
–
11
25
–
System 170
45
–
–
12
45
–
Data cable: Ø6.5mm
System 130
22
–
–
10
22
–
System 170
39
–
–
11
39
–
Data cable: Ø7.0mm
System 130
19
–
–
8
19
–
System 170
33
–
–
9
33
–
Data cable: Ø8.4mm
System 130
13
–
–
6
13
–
System 170
23
–
–
6
23
–
Cable capacities
• All calculations allow for a 45% space factor.
As there can be differences between data cable sizes,
Marshall-Tufflex recommend that cable dimensions are
confirmedwith themanufacturing company.
Compartments 1 & 3 = 2812mm² (each) total area
Compartments 1 & 3 = 1265mm² (each) 45% space factor
Compartment 2 = 760mm² total area (with box)
Compartment 2 = 342mm² 45% space factor (with box)
System 130 trunking
130 x 63mm
System 170 trunking
170 x 63mm
Compartments 1 & 3 = 1585mm² (each) total area
Compartments 1 & 3 = 760mm² (each) 45% space factor
Compartment 2 = 713mm² total area (with box)
Compartment 2 = 342mm² 45% space factor (with box)
Dimensions
To determine cable
capacity, select the size of
the cable required and its
corresponding cable factor
from the table. Divide the
compartment area figure
(with or without 45% space
factor) with the cable factor
figure to achieve cable
capacity.
Steel trunking Series 130 and Series
170 – continued
63
21
80
1
2
3
Box
40mm
Internal
Depth
40
130
63
21
80
1
2
3
Box
40mm
Internal
Depth
40
170
Conductor type
Size
Cable factor
Stranded PVC power
1.5mm²
8.0
Stranded PVC power
2.5mm²
11.9
Stranded PVC power
4.0mm²
16.6
*Data cable
Ø5.5mm 23.8
*Data cable
Ø6.0mm 28.3
*Data cable
Ø6.5mm 33.2
*Data cable
Ø7.0mm 38.5
*Data cable
Ø8.4mm 55.4
For Data cable information, please see page 246
