General Catalogue • Technical • tebis.KNX
Dimmers
Electrical Connection
TXA210N/TXA215 : 1 Output 600W / 1000W
TXA213N : Single phase 1-3 outputs
Functions and setting available on TXA215
• Display of the dimming level
• Dimming rise time from 0 to 100% adjustable from 1s to 60s (4s by default)
• Dimming start and stop time adjustable from 0s to 30min
• Setting of minimum dimming threshold : 1% per default
• Setting of maximum dimming threshold : 100% per default
• Setting of reached transition time for call of scenario of 0s to 9h59min
Plot dimmers TXA211
L
N
LED for
overload
indication
Auto/Manu
communicator
LED for short-circuit
and overload indication
LED for state indication
Control button for
manual mode
Physical light
addressing
L
N
LED for
overload
indication
Auto/Manu
communicator
LED for short-circuit
and overload indication
LED for state indication
Control button for
manual mode
Physical light
addressing
Commutator 3
positions :
- 3 x 300 W
- 1 x 600 W + 1 x
300 W
- 1 x 900 W
1 3 5 7 9 11
2 4 6 8 10 12
L
N
Bus
30 V
TBTS
1
5 7 3
9 11
16
12 10 14
13 15
6 8
1/10V 1/10V
min
max
auto
TXA211
EV 100
EV 102
Bus
30 V
TBTS
1
5 7 3
9 11
16
12 10 14
13 15
6 8
min
max
auto
TXA211
L
N
L N
-+
1-10 V
Auto/Manu
communicator
Electronic ballast
Fluorescent tube
Visualisation of
output state
Push-button for
priority setting of the
ways
EV100
EV102
