Dimmers
Technical Characteristics
Dimmers
The Tebis dimming offer includes:
• Dimmers with direct output 300, 600 or 1000 W
• Units with 1 or 3 outputs
Dimmers with Direct Output
Completely renewed, this extended range integrates the new design
and the quick connect system.
It includes the following products:
• TXA213N : 3 outputs 300 W
• TXA210N : 1 output 600 W
• TXA215 : 1 output 1000 W
• TXA210AN : 1 output 300W
These products allow the direct connection of the incandescent,
fluorescent, ELV halogen or LED loads. They adapt automatically with
the type of connected load and have an integrated overheating and
overload protection.
Other Advantages
• Manual control even when bus is disconnected.
• Mini/maxi level local setting
• Memorizing up to 8 different scene levels of lighting.
• Call of present level by priority setting
Dimmers 1-10 V : TXA211
The module TXA211 is provided for control by output:
• Up to 30 dimmers EV 100 or EV 102,
• Up to 25 electronic ballasts at 20mA
• Possibility to memorize up to 3 different scene lighting levels.
In manual mode, the push-buttons situated on the product allow the
priority setting of the outputs when there is supply voltage on the bus.
Dimming Principles
Only one push-button is needed to select a dimming circuit
according to following principle :
• 1 brief press = start or stop
• 1 long press = increase or decrease
At each switching on, the dimmer restores the last stored level,
except when scenes are called.
The dimming control is also possible with 2 push-buttons:
• 1 push-button for start or increase by short or long press
• 1 push-button for stop or decrease by short or long press
Technical Characteristics
TXA210AN
TXA210N
TXA213N
TXA215
TXA211
Number of outputs 1 Output 300W 1 Output 600W 1 to 3 Output
according to selector
1 Output 1000W 3 Outputs 1-10V
Dimming range in
230V or in ELV
ferromagnetic or
electronic transformer
25 to 600W / 600VA
20 to 300W / 300VA
20 to 600W / 600VA
20 to 900W / 900VA
20 to 1000W / VA Output 1-10V :
Current max. 50mA +
contact TOR 16A AC1
LED
up to 60W
up to 120W
up to 60W
up to 120W
up to 180W
Supply
30V DC + 230V - 50/60Hz
Max dissipation of the
product
4W
7.5W
9W
10W
9W
Working temperature 0 to +45ºC
-20 to +70ºC
Storage temperature -20 to +60ºC
Degree of protection IP30
Width of module
4
6
4
Connection
0.75 to 2.5mm
2
with flexible or rigid wire quick connect terminal
Flexible: 1 to 6mm
2
Rigid: 1.5 to 10mm
2
