641
CABLE MANAGEMENT
PERIMETER AND
DISTRIBUTION
POWERLINK PLUS CABLE CAPACITY
TYPE OF
CONDUCTOR SIZE
CABLE
FACTOR
COMPARTMENT
1
COMPARTMENT 1
WITH 25MM
BACKBOX
COMPARTMENT 1
WITH 35MM
BACKBOX
COMPARTMENT
1
Full Term CSA 100% Fill (MM
2
)
4510
2499
1857
460
TERM AT 45% FILL (MM
2
)
2029
1124
835
207
POWER CABLES
NUMBER OF CABLES AT 45% FILL
PVC
stranded
1.5mm
2
8.6
235
130
97
24
2.5mm
2
12.6
161
89
66
16
4mm
2
16.6
122
67
50
12
6mm
2
21.2
95
53
39
9
DATA CABLES
NUMBER OF CABLES AT 45% FILL (A) AND FULL CAPACITY (B)
A
B
A
B
A
B
A
B
Cat 5E UTP 5.5mm dia.
30.2
67
149
37
82
27
61
6
15
Cat 5E STP 6.0mm dia.
36.0
56
125
31
69
23
51
5
12
Cat 6 UTP 6.5mm dia.
42.2
48
106
26
59
19
44
4
10
Cat 6 STP 7.0mm dia.
49.0
41
92
22
51
17
37
4
9
Pinnacle Technical
Bench and Shelf Trunking
90
105
VERSION 1 PTS
105
90
VERSION 2 PTS
180
105
VERSION 3 PTD
1
2
2
1
1
1
2 2
20
13
Dimensions (mm)
COUPLER SET
PCWHI
PTS3WHI
EXTERNAL CORNER
PECLWHI
INTERNAL CORNER
PICLWHI
END CAPS
PECSWHI / PECSCOL
