CABLE MANAGEMENT
PERIMETER AND
DISTRIBUTION
PREMIER CABLE CAPACITY
TYPE OF
CONDUCTOR SIZE
CABLE
FACTOR
NCT5050 NCT7550 NCT7575 NCT1040 NCT1050 NCT1010
NCT1040
WITH
25MM
BACKBOX
NCT1050
WITH
25MM
BACKBOX
NCT1050
WITH
35MM
BACKBOX
NCT1010
WITH
25MM
BACKBOX
NCT1010
WITH
35MM
BACKBOX
Full Term CSA 100% Fill (MM
2
)
1881
3039
4754
3091
4041
8725
1081
1866
1224
6550
5908
TERM AT 45% FILL (MM
2
)
846
1367
2139
1390
1818
3926
486
839
550
2947
2658
POWER CABLES
NUMBER OF CABLES AT 45% FILL
PVC
stranded
1.5mm
2
8.6
98
158
248
161
211
456
56
97
63
342
309
2.5mm
2
12.6
67
108
169
110
144
311
38
66
43
233
210
4mm
2
16.6
50
82
128
83
109
236
29
50
33
177
160
6mm
2
21.2
39
64
100
65
85
185
22
39
25
139
125
DATA CABLES
NUMBER OF CABLES AT 45% FILL (A) AND FULL CAPACITY (B)
A B A B A B A B A B A B A B A B A B A B A B
Cat 5E UTP 5.5mm dia.
30.2 28 62 45 100 70 157 46 102 60 133 130 288 16 35 27 61 18 40 97 216 88 195
Cat 5E STP 6.0mm dia.
36.0 23 52 37 84 59 132 38 85 50 112 109 242 13 30 23 51 15 34 81 181 73 164
Cat 6 UTP 6.5mm dia.
42.2 20 44 32 72 50 112 32 73 43 95 93 206 11 25 19 44 13 29 69 155 62 140
Cat 6 STP 7.0mm dia.
49.0 17 38 27 62 43 97 28 63 37 82 80 178 9 22 17 38 11 24 60 133 54 120
ACCESSORIES
FOR USE WITH
LIST NO.
ONE GANG
ACCESSORY BOX
AND FRAME
NCT1040, NCT1050, NCT1010 for power and ELV
outlets requiring 25mm deep box NCT1050/NCT1010
for power and ELV outlets requiring 35mm deep box
NCT1040, NCT1050, NCT1010 for power and ELV
outlets requiring extra deep accessory space
VTS6025
VTS6035
VTS6000
TWO GANG
ACCESSORY BOX
AND FRAME
NCT1040, NCT1050, NCT1010 for power and ELV
outlets requiring 25mm deep box NCT1050/NCT1010
for power and ELV outlets requiring 35mm deep box
NCT1040, NCT1050, NCT1010 for power and ELV
outlets requiring extra deep accessory space
VTS7025
VTS7035
VTS7000
THREE GANG
ACCESSORY BOX
NCT1040, NCT1050, NCT1010 for power and ELV
outlets requiring 28mm deep box
VTS8028
MINI TRUNKING
ADAPTOR
Integrates Premier with YEA1, YEA2, YEA3 CMA1,
CMA3, CMA4 Mini trunking fittings
NYT100
Premier Technical
Applications
The Premier system is ideal for use in factories,
workshops, schools, portable accommodation
and general commercial buildings where
integration of cable distribution with accessory
mounting facility is desirable.
Generally systems can be used as follows:
50 x 50, 75 x 50 and 75 x 75mm – general cable
distribution.
100 x 40 and 100 x 50mm – where mounting
accessories are also required.
100 x 100mm – where mounting accessories
and/or generous cable distribution is required.
Dimensions (mm)
TRUNKING SYSTEMS
50
50
NCT5050
50
75
NCT7550
75
75
NCT7575
40
100
NCT1040
50
100
NCT1050
100
100
NCT1010
Integrated Trunking
