640
CABLE MANAGEMENT
PERIMETER AND
DISTRIBUTION
TECHNICAL SPECIFICATION
MATERIALS
PVCu materials used in the manufacture of MK
products are self extinguishing non-flame propagating
in accordance with BS 4678 Part 4.
Extrusion material has been tested by a UKAS
accredited laboratory in accordance with the
requirements of BS 476 Part 7 and has achieved a
Class 1Y.
Moulding material has been tested by a UKAS
accredited laboratory and conforms with IEC 695-2-1
at a severity of 650°C.
IET WIRING REGULATIONS
Designed and manufactured to comply in all respects
with BS 7671:2008 (IET Wiring Regulations 17th
Edition: 2008)
QUALITY ASSURANCE
The system is manufactured to BS EN ISO 9001
Classifications to BS EN 50085-1:2005 and
BS EN 50085-2-1:2006 available on request
For a full range of corresponding products,
see pages 332-337 in the product selector.
Pinnacle Technical
Description
Pinnacle is an angular bench trunking system ideally suited for distributing LV
electrical and communication services in laboratories, schools, workshops and other
applications where the service contacts are mounted on or above desks and benches.
Bench and Shelf Trunking
FEATURES
l
Available in a single or double configuration
l
May be fitted either direct to the work surface
or inverted above the working area
l
Cable segregation is provided by two separate
compartments with the facility to further
subdivide the main compartment by means of a
clip-in cable divider
l
Single profiles may be converted to a back to
back double assembly. A onepiece centre lid
and double end caps complete the coupling
l
Prefabricated internal and external corners
l
Coupler sets for greater strength and protection
l
Bench units are also available to match the
system
l
All extrusions manufactured from 100%
recycled material*
* Based on 2014 consumption
