624
CABLE MANAGEMENT
PERIMETER AND
DISTRIBUTION
CABLE CAPACITY
TYPE OF
CONDUCTOR SIZE
CABLE
FACTOR
COMPARTMENT 1
COMPARTMENT 1
WITH 25MM
BACK BOX
COMPARTMENT 1
WITH 35MM
BACK BOX
COMPARTMENT 1
EXT CORNER
50MM DATA BEND
Full Term CSA 100% Fill (MM
2
)
4466
2236
1633
3132
TERM AT 45% FILL (MM
2
)
2009
1006
734
1409
POWER CABLES
NUMBER OF CABLES AT 45% FILL
PVC
stranded
1.5mm
2
8.6
233
116
85
163
2.5mm
2
12.6
159
79
58
111
4mm
2
16.6
121
60
44
84
6mm
2
21.2
94
47
34
66
DATA CABLES
NUMBER OF CABLES AT 45% FILL (A) AND FULL CAPACITY (B)
A
B
A
B
A
B
A
B
Cat 5E UTP 5.5mm dia.
30.2
66
147
33
74
24
54
46
103
Cat 5E STP 6.0mm dia.
36.0
55
124
27
62
20
45
39
87
Cat 6 UTP 6.5mm dia.
42.2
47
105
23
52
17
38
33
74
Cat 6 STP 7.0mm dia.
49.0
41
91
20
45
14
33
28
63
Cat7
8.0mm dia.
64
12
27
26
59
4
9
13
30
FLAT ANGLES DIMENSIONS (MM)
LIST NO DESCRIPTION A B C D
VTS2012WHI
Flat angle 310 210
VTS2014WHI
Flat T details 310 210 410 210
Prestige 2Com
Technical
FLAT ANGLE
FLAT TEE
Flat Angles and
Tees
These components are
fabricated sections and
space must be allowed
for their inclusion in runs
of trunking. All other
components snap on over
standard trunking profiles.
COMPONENTS
VTS2001WHI main carrier +
2 x VTS5WHI straight covers
WEIGHT:
2.41 Kg/m
WALL THICKNESS:
VTS2001WHI = 2.5mm, 2.0m
VTS5WHI = 1.7mm
60
210
1
1
A
A
B
B
C
B
D
A
Data Trunking System
Dimensions (mm)
