CABLE MANAGEMENT
PERIMETER AND
DISTRIBUTION
Prestige 2Com
Technical
13mm
for joint
cover
Trunking Covers
to be cut
8-10mm shorter
than Trunking Base
Centre
12
13
14
15
16
17
10
e
18
Debur all cover cut ends
Insert accessories in the following order
a
Box adaptor
b
Accessory Boxes
c
Appropriate slide (VTS2081 shown)
d
Cross over bridge
e
External Corner Radius (into the Data/Telecom compartment)
Power Cables
Data / Communication cables
Mark position where mains entry is required
Installation Guide Continued
12
13
14
10
11
Data Trunking System
