CABLE MANAGEMENT
PERIMETER AND
DISTRIBUTION
WALL THICKNESS
Trunking base
2.4mm
Centre compartment cover
2.5mm
Curved cover
1.5mm
WEIGHT (KG)
TYPE
NUMBER OF
COMPARTMENTS
WITH SCREENING
1
2
Dado trunking without busbar
(K1903)
2.4
3.0
3.6
Dado trunking with busbar
(K1963)
3.0
3.6
4.2
POWERLINK PLUS CABLE CAPACITY
TYPE OF
CONDUCTOR
SIZE
CABLE
FACTOR
COMPARTMENT 1
(CURVED)
COMPARTMENT 2
(WITH BUSBAR)
COMPARTMENT 2
(WITH BUSBAR)
COMPARTMENT 3
(SQUARE)
Full Term CSA 100% Fill (MM
2
)
943
2968
2528
1044
TERM AT 45% FILL (MM
2
)
424
1335
1137
469
POWER CABLES
NUMBER OF CABLES AT 45% FILL
PVC
stranded
1.5mm
2
8.6
49
155
132
54
2.5mm
2
12.6
33
105
90
37
4mm
2
16.6
25
80
68
28
6mm
2
21.2
20
62
53
22
DATA CABLES
NUMBER OF CABLES AT 45% FILL (A) AND FULL CAPACITY (B)
A
B
A
B
A
B
A
B
Cat 5E UTP 5.5mm dia.
30.2
14
31
44
98
0
0
15
34
Cat 6 UTP 6.5mm dia.
42.2
10
22
31
70
0
0
11
24
Cat 6 STP 7.0mm dia.
49.0
8
19
27
60
0
0
9
21
Powerlink Plus
Technical
Dimensions (mm)
The dado trunking is divided into three compartments. Two
identical outer compartments are mainly for ELV cables with a
third central compartment containing the busbars with a cableway
above.
50
170
1
1
2
50
170
1
3
2
CROSS SECTION
THROUGH DADO
TRUNKING
CROSS SECTION
THROUGH SKIRTING AND
DADO TRUNKING
Skirting and Dado Trunking System
