Standards and Approvals
The Prestige 2com trunking is a symmetrical
two compartment system offering a Cat 7
flexible solution to routing data cabling whilst
maintaining a slow bend radius of 50mm, with a
separate compartment for power cables.
The trunking is normally surface mounted at
dado or skirting height but may also be used
vertically. The covers are of the snap-on type
with the option of screw fixing for added security
against vandalism. Special accessories include
adaptors for connection to the full range of MK
Ega Mini Trunking.
TECHNICAL SPECIFICATION
MATERIALS
All components are manufactured from PVCu.
Carriers, covers and cable dividers are extruded.
Carrier couplers, corner carriers, stop ends and accessory
boxes are formed by injection moulding.
COLOURS
The system is available in a standard white colour.
OUTLETS
The system is designed to accommodate the
complementary range of Logic Plus switches and
sockets. Other MK wiring devices may also be used.
Classifications to BS EN 50085-1:2005 and
BS EN 50085-2-1:2006 available on request.
FEATURES
l
System bend radius 50mm
Exceeds Cat 5e, 6 and 7 data cable
requirements
l
Attractive styling complementary to
Logic Plus
l
Aesthetic one piece fitting covers with
carriers
l
Two equal compartments – maximises
wiring compartment capacity
l
Accessory mounting in either or both
compartments – giving flexibility/
versatility
l
Unobtrusive screw fixing covers to
maximise security against tampering
l
Ease of installation – butt jointed
construction, no mitring required
l
Economical – cost effective 3
components (2 x lids, 1 base)
l
Suitable for skirting or dado mounting
l
Pre-drilled base – ease/speed of
installation
l
Accommodates matching MK and
other BS switches and sockets
l
Interfaces with MK Premier, Ega
Industrial and Ega Mini Trunking and
Conduit Systems
l
Strong PVCu sections are resistant to
impact
l
Manufactured to high precision
standards
l
Full range of components, spares and
accessories
l
Mounting frames for LJU6C and Euro
data outlets – cost effective, minimum
space requirement (for mounting in
SELV compartment only)s
l
All extrusions manufactured from
100% recycled material*
For a full range of corresponding products,
see pages 311-316 in the product selector.
Prestige 2Com
Technical
* Based on 2014 consumption
Description
The Prestige 2com trunking is a symmetrical two compartment system offering a
Cat 7 flexible solution to routing data cabling whilst maintaining a slow bend radius
of 50mm, with a separate compartment for power cables. The trunking is normally
surface mounted at dado or skirting height but may also be used vertically. The
covers are of the snap-on type with the option of screw fixing for added security
against vandalism. Special accessories include adaptors for connection to the full
range of MK Ega Mini Trunking.
Data Trunking System
