CABLE MANAGEMENT
PERIMETER AND
DISTRIBUTION
FABRICATED ANGLES AND TEES DIMENSIONS (MM)
LIST NO
DESCRIPTION
A
B
C
D
VCT145WHI
Flat Angle 140 (Dado)
190mm 140mm
VCT147WHI
Flat Tee 140 (Dado)
200mm 140mm 235mm 140mm
VCT165WHI
Flat Angle – Up 160 (Extended Dado)
215mm 160mm
VCT166WHI
Flat Angle – Down 160 (Extended Dado)
215mm 160mm
VCT167WHI
Flat Tee – Up 160 (Extended Dado)
220mm 160mm 235mm 140mm
Prestige 3D Technical
– Compact
Component Selection Guide
A
A
B
B
D
B
A
C
20
70
13
13
20
70
13
13
20
70
13
13
PROFILE END CAP
140MM VCT143WHI
160MM VCT163WHI
Data Trunking System
PROFILE INTERNAL CORNER
140MM VCT141WHI
160MM VCT161WHI
PROFILE INTERNAL CORNER
140MM VCT141WHI
160MM VCT165WHI
FLAT ANGLE DOWN
VCT145WHI
VCT166WHI
PROFILE JOINT COVER
140MM VCT144WHI
160MM VCT164WHI
PROFILE EXTERNAL CORNER
140MM VCT142WHI
160MM VCT162WHI
PROFILE FLAT TEE UP
140MM VCT147WHI
160MM VCT167WHI
FLAT TEE DOWN
VCT147WHI
Flat Angles and Tees
