WIRING DEVICES
Technical Hotline
+44 (0)1268 563720
INGRESS PROTECTED
Switchsocket Outlets
Interlocked Surface Mounting
16 and 32 Amp
Switchsocket Outlets
Interlocked Surface Mounting
63 Amp
ø25
243
170
90
120
149
AMPS
PIN.
CONFIGURATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
CABLE ENTRY
KNOCKOUTS
TERMINAL
CAPACITY*
MM
2
FIXING
CENTRES
MM
LIST NO
LIST NO
LIST NO
16A
3P+E
K13607RED
6
2 x Ø25 top
1.5-4
90 x 170
32A
2P+E
K13632YEL
4
2 x Ø25 top
2.5-10
90 x 170
32A
3P+E
K13637RED
6
2 x Ø25 top
2.5-10
90 x 170
Earth Hour Position
*Solid or Stranded conductors
AMPS PIN.
CONFIG-
URATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
120/208-
144/250V
50-60HZ
200/346-
240/415V
50-60HZ
DIMENSIONS IN
MM
TERMINAL
CAPACITY*
MM
2
CABLE ENTRY
KNOCKOUTS
FIXING
CENTRES
LIST NO
LIST NO
LIST NO
LIST NO
LIST NO
A
B
16A
2P+E K73600YEL
4
K73601BLU
6
228 128.5 1.5-4 Ø20/25+Ø25/32
top and bottom 108×165
16A
3P+N+E
K73603BLU
9
K73615RED
6
229 142.5 1.5-4 Ø20/25+Ø25/32
top and bottom 108×165
32A
2P+E
K73633BLU
6
235.5 148
2.5-10 Ø20/25+Ø25/32
top and bottom 108×165
32A
3P+E
K73637RED
6
235.5 148
2.5-10 Ø20/25+Ø25/32
top and bottom 108×165
32A
3P+N+E
K73635BLU
9
K73641RED
6
235.5 154.5 2.5-10 Ø20/25+Ø25/32
top and bottom 108×165
Earth Hour Position
*Solid or Stranded conductors
AMPS PIN.
CONFIG-
URATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
120/208-
144/250V
50-60HZ
200/346-
240/415V
50-60HZ
DIMENSIONS IN
MM
TERMINAL
CAPACITY*
MM
2
CABLE ENTRY
KNOCKOUTS
FIXING
CENTRES
LIST NO
LIST NO
LIST NO
LIST NO
LIST NO
A
B
63A
3P+N+E
K73643RED
6
301
175
6-25 2×Ø32/40 top and
bottom 123×225
Earth Hour Position
*Solid or Stranded conductors
IP44 SPLASHPROOF
Switch Utilisation Category AC 22A
Will accept auxiliary contacts
6813
and
6814
Switch can be locked in open or closed position.
(SUITABLE FOR TOP ENTRY)
Commando Technical
B
152.8
215
A
152.8
B
168.6
275
A
152.8
