560

WIRING DEVICES

mkelectric.co.uk

INGRESS PROTECTED

Socket Outlets

Angled Surface

Mounting

63 Amp

Socket Outlets

Straight Panel Mounting

16 and 32 Amp

ALL FLANGES HAVE THE SAME FIXING CENTRES AND OUTSIDE DIMENSIONS

TO ASSIST PANEL BUILDING.

IP44 SPLASHPROOF

IP67 WATERTIGHT

Commando Technical

AMPS

PIN.

CONFIURATION

200-250V

50-60HZ

380-415V

50-60HZ

TERMINAL

CAPACITY*

MM

2

DIMENSIONS

IN MM

LIST NO

LIST NO

A

B

C

D

63A

2P+E

K9857BLU

6-16

300.8

165.4

274.5

135

63A

3P+E

K9858RED

300.8

166.1

275

135

63A

3P+N+E

K9859RED

6-16

300.8

166.1

275

135

Earth Hour Position

*Flexible conductors

AMPS

PIN.

CONFIURATION

100-130V

50-60HZ

200-250V

50-60HZ

380-415V

50-60HZ

CABLE

DIAMETER D MM

TERMINAL

CAPACITY*

MM

2

DIMENSIONS IN MM

LIST NO

LIST NO

LIST NO

MIN MAX

A

B

C

D

E

F

16A

2P+E

K9400YEL

4

K9401BLU

6

8.2

13

1-2.5

70

56

41

20.9

50

83

32A

2P+E

K9432YEL

4

K9433BLU

6

11.7

18

2.5-6

70

56

55

26.5 60.4

92

32A

3P+N+E

K9445RED

6

11.1

22

2.5-6

70

56

55

26.5 60.4 98.5

Earth Hour Position

*Solid or Stranded conductors

A

B

D

E

F

ØC

Ø 5.5

A

B

C

D
