MK Electric Catalogue No. 49

564 / 759

564
WIRING DEVICES
INGRESS PROTECTEDSocket Outlets
Loop in Surface Mounting
16 and 32 Amp
120
90
170
243
149
ø25
Ø x2
171
AMPS PIN.
CONFIGURATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
CABLE ENTRY
KNOCKOUTS
TERMINAL
CAPACITY*
MM 2
FIXING
CENTRES
MM
LIST NO LIST NO LIST NO
32A 2P+E K13232YEL 4 2 x Ø25 top 2 x (2.5-10) 90 x 170
Earth Hour Position *Solid or Stranded conductors
AMPS PIN.
CONFIGURATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
TERMINAL
CAPACITY*
MM 2
DIMENSIONS IN MM
LIST NO LIST NO LIST NO A B C D
16A 2P+E K13300YEL K13301BLU 1-2.5 227.7 143.5 215 120
32A 2P+E K13333BLU 2.5-6 235.5 143.5 215 120
32A 3P+N+E K13341RED 2.5-6 235.5 143.5 215 120
Earth Hour Position *Solid or Stranded conductors
IP44 SPLASHPROOF
Commando Technical
A
B
C
D
