WIRING DEVICES
Technical Hotline
+44 (0)1268 563720
INGRESS PROTECTED
Switchsocket Outlets
Interlocked Angled Surface Mounting
63 Amp
Splashproof Appliance Inlets
Angled Surface Mounting
16 and 32 Amp
63 amp
With 32mm knockouts top and bottom.
Will accept FL13 flange top and bottom.
Switch can be locked in open position or closed position.
Switch Utilisation Category AC 22A
AMPS
PIN.
CONFIG-
URATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
TERMINAL
CAPACITY*
MM
2
DIMENSIONS IN MM
FIXING
CENTRES
CONDUIT
ENTRY
LIST NO
LIST NO
LIST NO
A
B
C
63A
3P+E
K9342RED
6
6-25
182
168
206
152 x 132
2 x 32mm
Earth Hour Position
*Solid or Stranded conductors
AMPS PIN.
CONFIG-
URATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
CABLE
DIAMETER
TERMINAL
CAPACITY*
MM
2
DIMENSIONS IN MM
TOP
CONDUIT
ENTRY D
REAR
ENTRY G
LIST NO
LIST NO
LIST NO
MIN MAX
B C C1 E1 F H I
16A
2P+E
K9701BLU
6
8.2 14 1.5-10 66 75 54 72 5.5 110 30
M20
Ø23
32A
2P+E
K9733BLU
6
11.7 19.5 1.5-10 85 111 72 94 5.5 153 33
M25
Ø29
Earth Hour Position
*Solid or Stranded conductors
TOP CONDUIT OR REAR CABLE ENTRY, COMPLETE
WITH BLANKING PLUG
IP44 SPLASHPROOF
IP67 WATERTIGHT
Commando Technical
ØC
G
F
D
E
H
I
B
A
A
C
Ø7.0
B
