569 / 759
569
WIRING DEVICES
Technical Hotline
+44 (0)1268 563720
INGRESS PROTECTED
Switchsocket Outlets
Interlocked Pre-wired with 30mA RCD
16 and 32 Amp
For a full range of corresponding products,
see pages 264-267 in the product selector.
Ø25
AMPS
PIN.
CONFIGURATION
100-130V
50-60HZ
200-250V
50-60HZ
200/346-240/415V
50-60HZ
RCD
TERMINAL
CAPACITY*
MM
2
EARTH
TERMINAL
CAPACITY*
MM
2
CABLE ENTRY
KNOCKOUTS
LIST NO
LIST NO
LIST NO
MIN MAX MIN MAX
16A
2P+E
K13309YEL
4
1.5 35 2.5 25 2 x Ø25 top
16A
3P+E
K13311RED
6
1.5 35 2.5 25 2 x Ø25 top
16A
3P+N+E
K13312RED
6
1.5 35 2.5 25 2 x Ø25 top
32A
2P+E
K13342YEL
4
K13343BLU
6
2.5 35 2.5 25 2 x Ø25 top
32A
3P+E
K13344RED
6
2.5 35 2.5 25 2 x Ø25 top
32A
3P+N+E
K13345RED
6
2.5 35 2.5 25 2 x Ø25 top
Earth Hour Position
*Solid or Stranded conductors
IP44 SPLASHPROOF
AMPS
PIN.
CONFIGURATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
200/346-240/415V
50-60HZ
DIMENSIONS
IN MM
TERMINAL
CAPACITY*
MM
2
CABLE ENTRY
KNOCKOUTS
FIXING
CENTRES
LIST NO
LIST NO
LIST NO
LIST NO
A
B
16A
2P+E
K73309YEL
4
K73310BLU
6
325 136.5 1.5-10 Ø20/25+Ø25/32
top and bottom 118×261
16A
3P+E
K73311RED
6
325 143.5 1.5-10 Ø20/25+Ø25/32
top and bottom 118×261
16A
3P+N+E
K73312RED
6
326 150.5 1.5-10 Ø20/25+Ø25/32
top and bottom 118×261
32A
2P+E
K73342YEL
4
K73343BLU
6
333
156
1.5-10 Ø20/25+Ø25/32
top and bottom 118×261
32A
3P+E
K73344RED
6
333
156
1.5-10 Ø20/25+Ø25/32
top and bottom 118×261
32A
3P+N+E
K73345RED
6
333
162
1.5-10 Ø20/25+Ø25/32
top and bottom 118×261
Earth Hour Position
*Solid or Stranded conductors
Commando Combi™
Technical
317
130
164.6
B
A
