MK Electric Catalogue No. 49

572 / 759

572
WIRING DEVICES
INGRESS PROTECTEDTwin Surface Socket Outlet
16 and 32 Amp
Twin Surface Socket Outlet
with Individual 30mA RCD Protection
16 and 32 Amp
IP44 SPLASHPROOF
AMPS PIN.
CONFIG-
URATION
100-130V
50-60HZ
200-250V
50-60HZ
EARTH TERMINAL
CAPACITY MM²
DIMENSIONS IN MM CABLE ENTRY KNOCKOUTS FIXING CENTRES
LIST NO LIST NO MIN MAX A D E G I J H K L BXF C
16A 2P+E K73143YEL 4 K73144BLU 6 1.5 10 252 6 4.5 228 158.8 118.7 2xØ40 4xØ32 4xØ40 200x210 160
Earth Hour Position
IP44 SPLASHPROOF
AMPS PIN.
CONFIG-
URATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
200/346-
240/415V
50-60HZ
EARTH
TERMINAL
CAPACITY
MM²
DIMENSIONS IN MM CABLE ENTRY
KNOCKOUTS
FIXING
CENTRES
LIST NO LIST NO LIST NO LIST NO MIN MAX A D E H J K I L M BXG CXF
16A 2P+E K73173YEL 4 K73174BLU 6 1.5 65 252 6 4.5 358 158.8 118.7 4xØ40 4xØ32 4xØ40 200x340 160x137
16A 3P+E K73175RED 6 1.5 65 252 6 4.5 358 158 118.7 4xØ40 4xØ32 4xØ40 200x340 160x137
16A 3P+N+E K73176RED 6 1.5 65 252 6 4.5 358 160.1 118.7 4xØ40 4xØ32 4xØ40 200x340 160x137
32A 2P+E K73184BLU 6 1.5 65 252 6 4.5 358 170.5 118.7 4xØ40 4xØ32 4xØ40 200x340 160x137
32A 3P+E K73185RED 6 1.5 65 252 6 4.5 358 170.5 118.7 4xØ40 4xØ32 4xØ40 200x340 160x137
32A 3P+N+E K73186RED 6 1.5 65 252 6 4.5 358 171.1 118.7 4xØ40 4xØ32 4xØ40 200x340 160x137
Earth Hour Position
Commando Combi™
Technical
ØH
ØH ØK
J
I
G F
A
C
B
ØD
ØE
G
F
A
C
B
ØD
ØE
H
ØI
ØM ØL
K
J
