WIRING DEVICES
mkelectric.co.ukINGRESS PROTECTED
Switchsocket Outlets
Interlocked Angled Surface Mounting
16, 32 and 63 Amp
Switchsocket Outlets
Interlocked Angled Conduit Entry
Surface Mounting
63 Amp
16 amp and 32 amp
Will accept auxiliary contact eg. 6813 and 6814
M32/M25 conduit entry, with mounting for FL9 flange plate
63 amp
M40 conduit entry with mounting for FL 13 flange plate
Switch Utilisation Category AC 22A
16 amp and 32 amp
With 29mm knockout at top.
Will accept FL13 flange.
Bottom entry M25.
63 amp
FL13 flange entry at top.
Supplied with cover plate and gland plate.
Switch Utilisation Category AC 22A
SWITCH CAN BE LOCKED IN OPEN OR CLOSED POSITION
AMPS
PIN.
CONFIGURATION
200-250V
50-60HZ
380-415V
50-60HZ
TERMINAL
CAPACITY*
MM
2
DIMENSIONS IN MM
FIXING
CENTRES
LIST NO
LIST NO
A
B
C
16
3P+E
K9601BLU
9
1.5-10
125
198
135
91.5 x 165
16
3P+N+E
K9607BLU
9
1.5-10
125
198
135
91.5 x 165
32
3P+E
1.5-10
135
198
135
91.5 x 165
32
3P+N+E
K9639BLU
9
1.5-10
135
198
135
91.5 x 165
63
3P+E
K9665RED
6
6-25
183
228
165
91.5 x 201
63
3P+N+E
6-25
183
228
165
91.5 x 201
Earth Hour Position
*Solid or Stranded conductors
AMPS
PIN.
CONFIG-
URATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
TERMINAL
CAPACITY*
MM
2
DIMENSIONS IN MM
FIXING
CENTRES
CONDUIT
ENTRY
LIST NO
LIST NO
LIST NO
A
B
C
63
2P+E
K9306BLU
6
6-25
168
168
206
152 x 132
2 x 32mm
Earth Hour Position
*Solid or Stranded conductors
IP44 SPLASHPROOF
IP44 SPLASHPROOF
Commando Technical
A
C
B
Ø5.5
A
C
D
Ø7
B
B
