WIRING DEVICES
mkelectric.co.ukINGRESS PROTECTED
Plugs 16 and 32 Amp
Plugs 63 Amp
Plugs 16 and 32 Amp
IP44 SPLASHPROOF
IP67 WATERTIGHT
IP44 SPLASHPROOF
Commando Technical
C
ØA
A
B
B
C
ØD
ØD
AMPS
PIN.
CONFIURATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
CABLE
DIAMETER D MM
TERMINAL
CAPACITY*
MM
2
DIMENSIONS
IN MM
LIST NO
LIST NO
LIST NO
MIN
MAX
A
B
C
16A
2P+E
K9000YEL
K9001BLU
6
8.2
13
1-2.5
132.3 95.5 55.5
16A
3P+E
K9006BLU
6
K9007RED
6
8.9
15.5
1-2.5
132.3 95.5 61.5
16A
3P+N+E
K9014BLU
9
K9015RED
6
10.1
17
1-2.5
132.3 95.5 67.5
32A
2P+E
K9032YEL
4
K9033BLU
6
11.7
18
2.5-6
135.8 90
72.5
32A
3P+E
K9036BLU
K9037RED
6
11.7
22
2.5-6
135.8 90
72.5
32A
3P+N+E
K9044BLU
9
K9045RED
6
14.2
22
2.5-6
141.8 95.8 79.7
Earth Hour Position
*Flexible conductors
AMPS
PIN.
CONFIURATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
CABLE
DIAMETER D MM
TERMINAL
CAPACITY*
MM
2
DIMENSIONS
IN MM
LIST NO
LIST NO
LIST NO
MIN
MAX
A
B
C
D
63A
2P+E
K9063BLU
6
16.5
36
6-16
102 180.8 247.3 36.4
63A
3P+E
K9066RED
6
16.5
36
6-16
102 180.8 247.3 36.4
63A
3P+N+E
K9071RED
6
16.5
36
6-16
102 180.8 247.3 36.4
Earth Hour Position
*Flexible conductors
AMPS
PIN.
CONFIURATION
100-130V
50-60HZ
200-250V
50-60HZ
380-415V
50-60HZ
CABLE
DIAMETER D MM
TERMINAL
CAPACITY*
MM
2
DIMENSIONS
IN MM
LIST NO
LIST NO
LIST NO
MIN
MAX
A
B
C
16A
2P+E
K9023YEL
4
K9024BLU
6
8.2
13
1-2.5
72
81.2 117.6
16A
3P+E
K9025RED
6
8.9
17
1-2.5
75.4 87.2 123.6
16A
3P+N+E
K9026RED
6
10.1
17
1-2.5
88
93.6 129.6
32A
2P+E
K9054BLU
6
11.7
18
2.5-6
92
97.2 142.6
32A
3P+E
32A
3P+N+E
K9056RED
6
14.2
22
2.5-6
98 102.9 148.3
Earth Hour Position
*Flexible conductors
C
ØA
B
ØD
