WIRING DEVICES
INGRESS PROTECTEDK6725
K6816
For a full range of corresponding products,
see pages 250-253 in the product selector.
W
H
D
X
X
Y
Y
W
H
D
X
X Y
K6725
LIST
NUMBER
ITHE
(A)
IE
(AC23A)
RATED
OPERATIONAL
POWER (KW)
TERMINAL
CAPACITY
(MM²)
NO OF
POLES
MAX.
NUMBER OF
ADDITIONAL
AUXILIARY
CONTACTS
ADDITIONAL
AUXILLARY
CONTACT
(NO)
LIST
NUMBER
(NOT
SUPPLIED)
ADDITIONAL
AUXILLARY
CONTACT
(NC)
LIST
NUMBER
(NOT
SUPPLIED)
DEGREE OF
INGRESS
PROTECTION
ENCLOSURE
SIZE (MM)
CABLE
ENTRY
FIXING
DIMENSIONS
(MM)
W H D X Y A B G
K6725 25 20 11 1.5-4
6 (2xL1,
2xL2 &
2xL3)
2 6818 6819 IP65 190 130 65 2 x Ø25 1 x Ø16 124 90 5
K6725YEL 25 20 11 1.5-4
7 (2xL1,
2xL2,
2xL3 &
AUX)
2 6818 6819 IP65 190 130 65 2 x Ø25 1 x Ø16 124 90 5
K6816
LIST
NUMBER
ITHE
(A)
IE
(AC23A)
RATED
OPERATIONAL
POWER (KW)
TERMINAL
CAPACITY
(MM²)
NO OF
POLES
MAX.
NUMBER OF
ADDITIONAL
AUXILIARY
CONTACTS
ADDITIONAL
AUXILLARY
CONTACT
(NO)
LIST
NUMBER
(NOT
SUPPLIED)
ADDITIONAL
AUXILLARY
CONTACT
(NC)
LIST
NUMBER
(NOT
SUPPLIED)
DEGREE OF
INGRESS
PROTECTION
ENCLOSURE
SIZE (MM)
CABLE
ENTRY
FIXING
DIMENSIONS
(MM)
W H D X Y A B G
K6816 16 10 7.5 1.5-4
3
(L1, L2,
& L3)
1 6818 6819 IP65 111 130 60 2xM25 - 64 90 5
K6816YEL 16 10 7.5 1.5-4
3
(L1, L2,
L3 &
AUX)
1 6818 6819 IP65 111 130 60 2 x Ø25 - 64 90 5
Commando Safetyswitch
Technical
