WIRING DEVICES
Technical Hotline
+44 (0)1268 563720
INGRESS PROTECTED
IP66
549
Standards and approvals
Telephone sockets K5820 and K5821 comply
with the following: BS 6312-2.
K5844/K5845/K5845s comply with:
ISO/IEC 11801, EN 50173, TIA 568, and
EN 41003.
K5887 complies with FCC68 and EN 41003.
TECHNICAL SPECIFICATION
PHYSICAL
AMBIENT OPERATING TEMPERATURE
0°C to +40°C
IP RATING
IP66
MAX. INSTALLATION ALTITUDE
2000 metres
Euro Enclosure and Telephone and Data Modules
Description
A range of Euro telephone, data and blank modules and weatherproof enclosure.
Enclosure accommodates 2 modules providing care is used to ensure that the cables
are correctly routed through the outlet.
MODULE DIMENSIONS (MM)
25 x 50
Installation (Telephone socket
modules)
Product performance, systems compatibility
Master Sockets: For use as the first socket
outlet on a direct exchange. They contain the
required surge protector (for line protection
against electrical surges) and ringing capacitor.
Secondary Sockets: for use as extension
sockets when connected on the same line as a
Master Socket.
For euro module wiring diagrams, please refer to wiring
devices technical section, pages 467-475
FEATURES
l
IP66 protected to BS EN 60529:1992
l
Ideal for gardens, workshops, industry,
commercial, public areas, farm
buildings, ponds, pools etc.
l
Easy to install: fixed gasket, captive
backed out terminal screws, clearly
marked top access angled terminals,
push fit knockouts and conduit entries,
rear drill holes
l
Patented gel seal provides durable
water and dust tight seal for
improved protection
l
Improved catch eases opening and
closing during use
l
Manufactured from polycarbonate
for impact protection
l
Products are available in grey, white
and black
Masterseal Plus™
