513
Keycard Switch with Time Delay
Description
The Elements Keycard Switch with Time Delay has been developed along with
a number of other products for hotels and hospitality venues, offering guests
comfort and control, whilst delivering energy efficiency by avoiding energy waste in
unoccupied rooms.
The Keycard Switch has a fixed time delay; once the card is removed guests are
not left in the dark.
BOX TYPES
Flush
Flush (for extra wiring space)
1 Gang
866ZIC (35mm deep)
877ZIC (46mm deep)
Dimensions (mm)
N in
L in
L out
Load
220-240V~
Time
Delay
Circuit
86
86
13.2
22.9
Wiring Diagram
Features
l
16 standard finishes
l
Many more customised
combinations of standard colours,
materials and finishes available
l
30 Second fixed time delay
l
Bespoke colours, materials
and finishes available via the
Design Service
Standards and approvals
BS EN 60669-2-1
TECHNICAL SPECIFICATION
ELECTRICAL
VOLTAGE RATING
220-240V, 50/60Hz
CURRENT RATING
10A
TERMINAL CAPACITY
4 x 1.5mm²
2 x 2.5mm²
1 x 4.0mm²
1 x 6.0mm²
EARTH TERMINAL
3 x 2.5mm²
2 x 4.0mm²
1 x 6.0mm²
CONTACT GAP
Micro Gap
PHYSICAL
AMBIENT OPERATING TEMPERATURE
0°C to +35°C
IP RATING
IP2X
MAX. INSTALLATION ALTITUDE
2000m
TIME DELAY (NON ADJUSTABLE)
30 seconds
