NP LV HRC fuse switch disconnectors
3/71
Siemens ET B1 · 10/2008
3
*
You can order this quantity or a multiple thereof.
All fuse switch disconnectors with flat terminals must be used
with the appropriate cable lug covers (3NY7 101 to 3NY7 141)
for finger-safe cover according to BGV A2,
see page 3/76
.
1)
See LV HRC Fuse Links.
2)
Insert silver-plated isolating links.
3)
Can only be mounted on 5 mm thick busbars, a busbar thickness compensator
is required for 3NP42 and 3NP43;
see page 3/77
.
3
NP44 can only be mounted on busbars with a thickness of 10 mm!
4)
SIRIUS motor starter protectors, as standard with auxiliary switches
1
NO + 1 NC.
See Catalog LV 1
5)
For 3NP40 7 with output socket for auxiliary switch, the signal lead must be
ordered separately,
see page 3/77
.
In the case of 3NP41 to 3NP44, the
auxiliary switch must be connected over a 2.8 mm
×
0.5
mm flat terminal
according to DIN 46244-A.
Rated
residual
current
Connection type
(
double-ended)
For LV HRC
fuse links
acc. to
DIN 43620
1)
For
isolating
links
2)
Degree of protection IP00,
without fuse links,
without isolating links,
with terminal screws
I
u
Connection For
conductor
cross-section
DT Order No.
Price
per PU
PG PU PS*/
P. unit
Weight
per PU
approx.
A
mm
2
Size
Size
Unit(s) Unit(s) kg
For 40 mm busbar system
For busbars of width 12 mm or 15 mm and
thickness 5 mm or 10 mm
3)
With fuse monitoring by SIRIUS motor starter
protector
4)5)
With deep adapter, e.g. for installation in ALPHA meter
cabinets and ALPHA distribution boards (STAB/SIKUS)
160
Flat terminals Up to 2
×
70
(
M8)
Connection,
top
00
a. 000 00 a. 000 B
3
NP40 75-0FE01
103 1
1
1.812
Connection,
bottom
B
3
NP40 75-0FF01
103 1
1
1.780
Box terminals 2.5 ... 70 or
2
×
2.5 ... 16
Connection,
top
00
a. 000 00 a. 000 B
3
NP40 75-0FK01
103 1
1
1.820
Connection,
bottom
B
3
NP40 75-0FJ01
103 1
1
1.831
With flat adapter according to DIN 43620 -6,
for ALPHA distribution boards (STAB/SIKUS)
160
Flat terminals Up to 2
×
70
(
M8)
Connection,
top
00
a. 000 00 a. 000 B
3
NP40 75-1FE01
103 1
1
1.616
Connection,
bottom
B
3
NP40 75-1FF01
103 1
1
1.620
Box terminals 2.5 ... 70 or
2
×
2.5 ... 16
Connection,
top
00
a. 000 00 a. 000 B
3
NP40 75-1FK01
103 1
1
1.717
Connec-
tion, bottom
B
3
NP40 75-1FJ01
103 1
1
1.630
250
Flat terminals Up to 240
(
M10)
Connection,
top or
bottom
1
and 0 1 and 0 A
3
NP42 75-1FG01
103 1
1
4.210
