BETA Protecting

Low-Voltage Fuse Systems

3

NP LV HRC fuse switch disconnectors

3/72

Siemens ET B1 · 10/2008

3

*

You can order this quantity or a multiple thereof.

All fuse switch disconnectors with flat terminals must be used

with the appropriate cable lug covers (3NY7 101 to 3NY7 141)

for finger-safe cover according to BGV A2,

see page 3/76

.

1)

See LV HRC Fuse Links.

2)

Insert silver-plated isolating links.

3)

Can only be mounted on 5 mm thick busbars, a busbar thickness compensator

is required for 3NP42 and 3NP43;

see page 3/77

.

3

NP44 can only be mounted on busbars with a thickness of 10 mm!

4)

SIRIUS motor starter protectors, as standard with auxiliary switches 1 NO

+ 1 NC.

See Catalog LV 1

5)

For 3NP40 7 with output socket for auxiliary switch, the signal lead must be

ordered separately,

see page 3/77

.

In the case of 3NP41 to 3NP44, the

auxiliary switch must be connected over a 2.8 mm

×

0.5

mm flat terminal

according to DIN 46244-A.

Rated

residual

current

Connection type

(

double-ended)

For LV HRC

fuse links

acc. to

DIN 43620

1)

For

isolating

links

2)

Degree of protection IP00,

without fuse links,

without isolating links,

with terminal screws

I

u

Connection For

conductor

cross-section

DT Order No.

Price

per PU

PG PU PS*/

P. unit

Weight

per PU

approx.

A

mm

2

Size

Size

Unit(s) Unit(s) kg

For 60 mm busbar system

For busbars of width 12 mm or 15 mm and

thickness 5 mm or 10 mm

3)

Flat, T and I profiles, as well as on Rittal PLS systems

With fuse monitoring by SIRIUS motor starter

protector

4)5)

160

Flat terminals Up to 2

×

70

(

M8)

Connection,

top

00

and 000 00

B

3

NP40 76-1FE01

103 1

1

1.670

Connection,

bottom

A

3

NP40 76-1FF01

103 1

1

1.890

Box terminals 2.5 ... 70 or

2

×

2.5 ... 16

Connection,

top

00

and 000 00

B

3

NP40 76-1FK01

103 1

1

1.755

Connection,

bottom

B

3

NP40 76-1FJ01

103 1

1

1.915

250

Flat terminals Up to 150

(

M10)

Connection,

top or

bottom

1

and 0 1 and 0 A

3

NP42 76-1FG01

103 1

1

4.171

400

Flat terminals Up to 240

(

M10)

Connection,

top or

bottom

2

and 1 2 and 1 A

3

NP43 76-1FG01

103 1

1

5.845

630

Flat terminals Up to 2

×

240

(

M12)

Connection,

top or

bottom

3

and 2 3 and 2 A

3

NP44 76-1FG01

103 1

1

8.235
