Busbar Systems
8US 40 mm Busbar Systems
Basic assemblies up to 400 A
10/8
Siemens LV 10 · 2014
* You can order this quantity or a multiple thereof.
10
■
Overview
40 mm busbar system: Basic assembly up to 400 A
■
Selection and ordering data
2
3
4
5
1
NSE0_02112
Flat copper profile
Busbar support
Cover profile
Inlay part
Covering cap
2
3
4
5
1
Description
DT Article No.
Price
per PU
PU
(UNIT,
SET, M)
PS*/
P. unit
PG Weight
per PU
approx.
kg
%()
Busbar supports
End and intermediate holders
for flat copper profiles
8US1903-3AB00
12 mm x 5 mm, 12 mm x 10 mm,
15 mm x 5 mm, 15 mm x 10 mm
3-pole, with inside fixing
(PU = 2 busbar supports including
inlay parts for bar thickness 5 mm
and lateral finger-safe covers)
8US1903-3AB00
1 1 unit
143 0.186
8US1903-5AA00
5-pole,
12 mm x 5 mm
and
12 mm x 10 mm
with inside fixing
L1–L3
+ N + PE/N
8US1903-5AA00
1 1 unit
143 0.155
8WC5
$
Flat copper profiles
(flat profile, approx. 2.4 m long,
bare, according to EN 12167)
12 mm
5 mm
8WC5123
1 1 unit
143 1.100
15 mm
5 mm
8WC5121
1 1 unit
143 1.550
&
Cover profiles for busbars
8US1922-2CA00
12 mm
5 mm
1000 mm long
8US1922-2CA00
1 10 units 143 0.066
15 mm
5 mm
1000 mm long
8US1922-2AA00
1 10 units 143 0.153
