Busbar Systems
8US 60 mm Busbar Systems
Basic assemblies up to 630 A
10/10
Siemens LV 10 · 2014
* You can order this quantity or a multiple thereof.
10
■
Overview
60 mm busbar system: Basic assemblies up to 630 A
■
Selection and ordering data
Longitudinal stays and assembly kits for ALPHA distribution boards
Description
Dimensions DT Article No.
Price
per PU
PU
(UNIT,
SET, M)
PS*/
P. unit
PG Weight
per PU
approx.
mm
kg
Longitudinal stays
For mounting the assembly kits in
unequipped distribution boards,
two longitudinal stays are required for each
assembly kit width
Height
600
8GK4851-4KK00
1 1 set
039 0.838
750
8GK4851-5KK00
1 1 set
039 1.076
900
8GK4851-6KK00
1 1 set
039 1.302
1050
8GK4851-7KK00
1 1 set
039 1.528
1200
8GK4851-8KK00
1 1 set
039 1.763
1350
8GK4852-8KK00
1 1 set
039 2.000
Assembly kits
Comprising touch protection cover and
4 supports
Cutout width for three-phase busbar
systems
• 216 mm
300 × 250
8GK4801-2KK13
1 1 unit
039 0.500
• 466 mm
300 × 500
8GK4801-2KK23
1 1 unit
039 0.700
• 716 mm
300 × 750
8GK4801-2KK33
1 1 unit
039 0.900
• 216 mm
450 × 250
8GK4801-3KK13
1 1 unit
039 0.650
• 466 mm
450 × 500
8GK4801-3KK23
1 1 unit
039 0.900
• 716 mm
450 × 750
8GK4801-3KK33
1 1 unit
039 1.150
1 set = 2 stays
NSE0_02123
X
Y
Z
[
\
]
X
Y
Z
]
[
\
Blanking cover
Support for blanking covers
Cover profile
End cover
Busbar supports
Flat copper profile
