8US 60 mm Busbar Systems

Infeed and connection methods

from 630 A to 1 600 A

10/15

Siemens LV 10 · 2014

* You can order this quantity or a multiple thereof.

■

Overview

60 mm busbar system: Terminals and covers for infeed and connection methods

■

Selection and ordering data

Description Length Width Max.

current

Conductor

cross-sec-

tion

Stan-

dard

DT Article No.

Price

per PU

(UNIT,

SET, M)

PS*/

P. unit

PG Weight

per PU

approx.

mm mm A mm

8US1921-1AA00

Infeeds

Connecting terminal plate with cover

• 3-pole

200 20

1.5 ...16 UL 508

5SH3538

1 5 units 031 0.181

• 3-pole

200 54

300 6 ... 50 UL 508

8US1921-1BA00

1 1 unit

143 0.446

• 3-pole

200 81

400 35 ... 120 UL 508

8US1921-1AA00

1 1 unit

143 0.493

Outgoing modules for PE/N

Connection

module for

4th pole

(PE/N)

up to 16 mm,

must be

attached to an

adapter/

device holder

242 18

8US1200-0AA00

1 1 unit

143 0.116

5SH3 535

SR60 connecting terminal plates

3-pole with

cover,

suitable for

aluminum

conductors

(shown with-

out cover)

560 150 ... 300

5SH3535

1 1 unit

031 1.608

Terminal sets

8US1941-2AA03

3-pole with-

out cover for

round cables,

suitable for

aluminum

conductors

560 120 ... 300

8US1941-2AA03

1 1 unit

143 1.577
