Eaton Industrial Switchgear - Xboard Optimal switchgear enclosure

30 / 140

20/26 CI insulated enclosures
Mounting system
2010 CA08103002Z-EN
Basic enclosures
For use with Thread Part no.
Article no.
Price
See price
list
Std. pack
Mounting plates
Including 4 captive fixing screws
Galvanized steel, 3 mm thick
CI23 – M3-CI23
019709
5 off
CI43...: 1 x
CI45...: 2 x
– M3-CI43
029201
CI44 – M3-CI44
031574
CI45 – M3-CI45
003036
CI48 – M3-CI48
036320
Glass-fibre reinforced insulating material, 4 mm thick
Devices are secured using hank nuts
CI23 – IM4-CI23
086081
5 off
CI43...: 1 x
CI45...: 2 x
– IM4-CI43
088454
CI44 – IM4-CI44
090827
CI48 – IM4-CI48
093200
Hank nuts for insulating material mounting plate
M4 EM4-CI
002293
100 off
– M5 EM5-CI
002294
– M6 EM6-CI
002295
Notes
1)
CI…-125… CI…-150… CI…-200… CI…-250…
Mounting depth with mounting plate
Mounting depth with mounting rail
7.5 mm or 15 mm
Enclosure depth
125
150
110
117.5
175
135
150
142.5
200
225
185
192.5
250
275
235
242.5
M3-CI..., IM4-CI..., EM...-CI HPL20026EN
