CI insulated enclosures
Accessories for North America
2010 CA08103002Z-EN
Basic enclosures 20/25
BasicenclosuresAccessories forNorthAmerica
Mounting systemBasicenclosures
For use with Mounting
depth
Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America
mm
Doors
• Protection type IP65
• Door opening angle 180°
• Door hinges can be subsequently changed to left,
right, top or bottom.
• Adhesive film for marking the cutout
• Fixing screws
• Transparent
Mounting on all enclosure covers
D…-CI23-NA
T-CI23-NA
011925
1 off Product Standards UL 508A; CSA-C22.2 No.94;
IEC/EN 60529; CE marking
UL File No. E54120, E337418
UL CCN NITW
CSA File No. 27130
CSA Class No. 3211-07
NA Certification UL Listed, CSA certified
Specially designed for NA Yes
Suitable for Refer to main component
information
Mounting on all enclosure covers
D…-CI43-NA
T-CI43-NA
011957
Mounting on all enclosure covers
D…-CI44-NA and D…-CI48-NA
T-CI44-NA
012001
For use with enclosure size Part no.
Article no.
Price
See price
list
Std. pack Information relevant for export to North America
Flanges
187.5 mm FL2-X-NA
208310
10 off Product Standards UL 508A; CSA-C22.2 No.94;
IEC/EN 60529; CE marking
UL File No. E54120, E337418
UL CCN NITW
CSA File No. 27130
CSA Class No. 3211-07
NA Certification UL Listed, CSA certified
Specially designed for NA Yes
Suitable for Refer to main component
information
250 mm FL3-X-NA
012462
375 mm FL4-X-NA
208309
Spacers
For enlarging the cable entry space, in conjunction with
flange FL3‐X‐NA
ZRF3-NA
012479
2 off Product Standards UL 508A; CSA-C22.2 No.94;
IEC/EN 60529; CE marking
UL File No. E54120, E337418
UL CCN NITW
CSA File No. 27130
CSA Class No. 3211-07
NA Certification UL Listed, CSA certified
Specially designed for NA Yes
Suitable for Refer to main component
information
T-CI...NA, FL...NA, ZRF...NA HPL20025EN
