Eaton Industrial Switchgear - Xboard Optimal switchgear enclosure

35 / 140

CI insulated enclosures
MCB individual enclosures
2010 CA08103002Z-EN
Prepared enclosures 20/31
MCB individualenclosuresPreparedenclosures
Dimensions
mm
Single-pole miniature
circuit-breakers
( space unit)
Number
PE and N terminals
Number x cross-section
mm2
Model Part no.
Article no.
Price
See price
list
Std.
pack
Type cover Type door
MCB individual enclosures
• Metric cable entry knockouts in all sides
• Protection type IP65
• For flush mounting devices with size 1 to DIN 43880
• Transparent cover with quick-release fasteners, transparent door for operator access to devices fitted
• Mounting rails for snap-fitting the devices
• Blanking strip for unused locations, protective shroud with inscription label
• PE/N bars
• Fixing straps for wall mounting, cover fasteners can be sealed
• Enclosure depth 150 mm
9 On each 2 x (6 - 16)
On each 7 x (1 - 4)
Transparent – AE/I23E
029766
1 off
9 On each 2 x (6 - 16)
On each 7 x (1 - 4)
– Transparent AE/I23E/T
032139
27 On each 4 x (6 - 35)
On each 20 x (1 - 4)
Transparent – AE/I43E
000239
27 On each 4 x (6 - 35)
On each 20 x (1 - 4)
– Transparent AE/I43E/T
002612
45 On each 4 x (6 - 35)
On each 20 x (1 - 4)
Transparent – AE/I44E
004985
45 On each 4 x (6 - 35)
On each 20 x (1 - 4)
– Transparent AE/I44E/T
061937
Notes
- - - PE/N bars
1)
2)
1)
2)
1)
2)
250
187.5
250
375
125
125
125
125
375
375
A
1 x M32/20
6 x M20
2 x M16
B
2 x M32/20
4 x M25/16
4 x M20
4 x M16
C
2 x M50/20
6 x M25/16
8 x M20
D
1 x M50/32
6 x M25/16
E
1 x M50/32
2 x M40/25
8 x M25/16
2 x M20
F
1 x M63/40
6 x M25/16
10 x M20
2 x M16
AE/I... HPL20031EN
