19/34 Circuit-breakers, fuses
Miniature circuit-breakers for North America
2010 CA08103002Z-EN
www.eaton.comMiniaturecircuit-breakers forNorthAmerica
1 pole
2 pole
Rated operational
current
Interrupting
capacity
(SCCR)
Special approval for protection
of AWG 18 or AWG 16 to
NFPA70 (NEC) and NFPA 79
Part no.
Article no.
Price
See price
list
Std. pack
Part no.
Article no.
Price
See price
list
Std. pack
I
n
A
kA
Miniature circuit-breakers FAZ-RT
• With ring cable lug connection
• Characteristic B
• Switching capacity 15 kA IEC
1
10
AWG 18
FAZ-B1/1-RT
1)
132731
2 off
FAZ-B1/2-RT
1)
132750
1 off
1.5
10
AWG 18
FAZ-B1,5/1-RT
1)
132732
FAZ-B1,5/2-RT
1)
132751
2
10
AWG 18
FAZ-B2/1-RT
1)
132733
FAZ-B2/2-RT
1)
132752
3
10
AWG 18
FAZ-B3/1-RT
1)
132734
FAZ-B3/2-RT
1)
132753
4
10
AWG 18
FAZ-B4/1-RT
1)
132735
FAZ-B4/2-RT
1)
132754
5
10
AWG 18
FAZ-B5/1-RT
1)
132736
FAZ-B5/2-RT
1)
132755
6
10
AWG 18
FAZ-B6/1-RT
1)
132737
FAZ-B6/2-RT
1)
132756
7
10
AWG 18
FAZ-B7/1-RT
1)
132738
FAZ-B7/2-RT
1)
132757
8
10
AWG 16
FAZ-B8/1-RT
1)
132739
FAZ-B8/2-RT
1)
132758
10
10
AWG 16
FAZ-B10/1-RT
1)
132740
FAZ-B10/2-RT
1)
132759
13
10
–
FAZ-B13/1-RT
1)
132741
FAZ-B13/2-RT
1)
132760
15
14
–
FAZ-B15/1-RT
1)
132742
FAZ-B15/2-RT
1)
132761
16
14
–
FAZ-B16/1-RT
1)
132743
FAZ-B16/2-RT
1)
132762
20
14
–
FAZ-B20/1-RT
1)
132744
FAZ-B20/2-RT
1)
132763
25
14
–
FAZ-B25/1-RT
1)
132745
FAZ-B25/2-RT
1)
132764
30
10
–
FAZ-B30/1-RT
1)
132746
FAZ-B30/2-RT
1)
132765
32
10
–
FAZ-B32/1-RT
1)
132747
FAZ-B32/2-RT
1)
132766
35
10
–
FAZ-B35/1-RT
2)
132748
FAZ-B35/2-RT
2)
132767
40
10
–
FAZ-B40/1-RT
2)
132749
FAZ-B40/2-RT
2)
132768
1
2
1 3
2 4
FAZ-B...RT
