19/32 Circuit-breakers, fuses
Miniature circuit-breakers for North America
2010 CA08103002Z-EN
www.eaton.comMiniaturecircuit-breakers forNorthAmerica
1 pole
2 pole
Rated operational
current
Interrupting
capacity
(SCCR)
Special approval for protection
of AWG 18 or AWG 16 to
NFPA70 (NEC) and NFPA 79
Part no.
Article no.
Price
See price
list
Std. pack
Part no.
Article no.
Price
See price
list
Std. pack
I
n
A
kA
Miniature circuit-breakers FAZ-NA
• Characteristic D
• Switching capacity 15 kA IEC
0.5
10
AWG 18
FAZ-D0,5/1-NA
1)
102097
2 off
FAZ-D0.5/2-NA
1)
102177
1 off
1
10
AWG 18
FAZ-D1/1-NA
1)
102098
FAZ-D1/2-NA
1)
102178
1.5
10
AWG 18
FAZ-D0,5/1-NA
1)
102099
FAZ-D1.5/2-NA
1)
102179
2
10
AWG 18
FAZ-D2/1-NA
1)
102100
FAZ-D2/2-NA
1)
102180
3
10
AWG 18
FAZ-D3/1-NA
1)
102101
FAZ-D3/2-NA
1)
102181
4
10
AWG 18
FAZ-D4/1-NA
1)
102102
FAZ-D4/2-NA
1)
102182
5
10
AWG 18
FAZ-D5/1-NA
1)
102103
FAZ-D5/2-NA
1)
102183
6
10
AWG 18
FAZ-D6/1-NA
1)
102104
FAZ-D6/2-NA
1)
102184
7
10
AWG 18
FAZ-D7/1-NA
1)
102105
FAZ-D7/2-NA
1)
102185
8
10
AWG 16
FAZ-D8/1-NA
1)
102106
FAZ-D8/2-NA
1)
102186
10
10
AWG 16
FAZ-D10/1-NA
1)
102107
FAZ-D10/2-NA
1)
102187
13
10
–
FAZ-D13/1-NA
1)
102108
FAZ-D13/2-NA
1)
102188
15
14
–
FAZ-D15/1-NA
1)
102109
FAZ-D15/2-NA
1)
102189
16
14
–
FAZ-D16/1-NA
1)
102110
FAZ-D16/2-NA
1)
102190
20
14
–
FAZ-D20/1-NA
1)
102111
FAZ-D20/2-NA
1)
102191
25
14
–
FAZ-D25/1-NA
1)
102112
FAZ-D25/2-NA
1)
102192
30
10
–
FAZ-D30/1-NA
1)
102113
FAZ-D30/2-NA
1)
102193
32
10
–
FAZ-D32/1-NA
1)
102114
FAZ-D32/2-NA
1)
102194
35
10
–
FAZ-D35/1-NA
2)
102115
FAZ-D35/2-NA
2)
102195
40
10
–
FAZ-D40/1-NA
2)
102116
FAZ-D40/2-NA
2)
102196
1
2
1 3
2 4
FAZ-D...NA
HPL19032EN
