Mounting accessories
Pole
Rated
operational
current
Cross section Length
Part no.
Article no.
Price
See price
list
Std. pack
I
e
A
mm
2
m
Comb-shaped phase busbar
1-phase, 80 A
1
80
16
1
Z-GV-16/1P-1TE
271061
50 off
3-phase, 63 A
3
63
10
1
Z-GV-10/3P-3TE
271060
20 off
3-phase, 80 A
3
80
16
1
Z-GV-16/3P-3TE
271064
20 off
4-phase, 80 A
4
80
16
1
Z-GV-16/3P+N-4TE
271066
15 off
End caps
3
–
10
–
Z-AK-10/2+3P
271069
10 off
3
–
16
–
Z-AK-16/2+3P
271070
10 off
4
–
16
–
Z-AK-16/4P
271071
10 off
Incoming terminals
4.3 Nm, touch-proof busbar connection to
miniature circuit-breaker
–
–
25
–
FAZ-XK25
212116
50 off
M5: 3.0 Nm, M8: 4.3 Nm touch-proof
connection to FAZ-XIS... busbar
–
–
35
–
FAZ-XK35
212119
10 off
Busbar tag shroud
For masking of unused connections on the
busbar
–
–
–
–
ZV-BS-G
104903
10 off
Bracket for securing of covers
2 required per row of MCBs
–
–
–
–
REG-BB
212106
20 off
Terminal bracket, 80 A
Same extension terminal, turned by 180°
L1, N
80
–
–
ZV-L1/N-80A-10
263950
10 off
L1, N
80
–
–
ZV-L1/N-80A-36
263951
36 off
L1, N
80
–
–
ZV-L1/N-80A-100
263952
100 off
L2, L3
80
–
–
ZV-L2/L3-80A-10
263953
10 off
L2, L3
80
–
–
ZV-L2/L3-80A-36
263954
36 off
L2, L3
80
–
–
ZV-L2/L3-80A-100
263955
100 off
Busbars
1 m long.
–
50
–
1
ZV-SS
263956
10 off
–
80
–
1
ZV-SS-80A
263957
10 off
Shroud section
1 m long, for 50 and 80 A.
–
–
–
–
ZV-ADP
263958
1 off
End cap for shroud section
–
–
–
–
ZV-AEK
263959
10 off
