480 / 543
19/26 Circuit-breakers, fuses
Busbars
2010 CA08103002Z-EN
www.eaton.comPhases
Devices
Part no.
Article no.
Price
See price
list
Std. pack
Notes
Number
Number
Euro-Vario busbars (fork connector)
• No end caps required
• Do not shorten
16 mm
2
• Rated operational current 100 A
For FAZ…, FI…
1
2
EVG-16/1PHAS/2MODUL
291464
40 off
1
6
EVG-16/1PHAS/6MODUL
291465
40 off
1
12
EVG-16/1PHAS/12MODUL
291466
40 off
2
4
EVG-16/2PHAS/4MODUL
291467
20 off
2
6
EVG-16/2PHAS/6MODUL
291468
20 off
2
12
EVG-16/2PHAS/12MODUL
291469
20 off
3
6
EVG-16/3PHAS/6MODUL
291470
20 off
3
9
EVG-16/3PHAS/9MODUL
291471
20 off
3
12
EVG-16/3PHAS/12MODUL
291472
20 off
3
16
EVG-16/3PHAS/16MODUL
291473
20 off
3
20
EVG-16/3PHAS/20MODUL
291474
10 off
4
8
EVG-16/4PHAS/8MODUL
291475
10 off
4
12
EVG-16/4PHAS/12MODUL
291476
10 off
For combined use of 4 pole residual-current devices with miniature circuit-
breakers
3
4 + 5
EVG-16/3PHAS/N/5MODUL/LS
291477
20 off
3
4 + 8
EVG-16/3PHAS/N/8MODUL/LS
291478
20 off
For use with auxiliary contacts
1
2
EVG-16/1PHAS/2MODUL/HI
291479
20 off
1
6
EVG-16/1PHAS/6MODUL/HI
291480
40 off
1
9
EVG-16/1PHAS/9MODUL/HI
291481
40 off
2
2
EVG-16/2PHAS/4MODUL/HI
291482
20 off
2
3
EVG-16/2PHAS/6MODUL/HI
291483
20 off
2
5
EVG-16/2PHAS/10MODUL/HI
291484
20 off
3
2
EVG-16/3PHAS/6MODUL/HI
291485
20 off
3
4
EVG-16/3PHAS/12MODUL/HI
291486
20 off
3 x 1
6
EVG-16/3X1PHAS/6MODUL/HI
291487
20 off
3 x 1
8
EVG-16/3X1PHAS/8MODUL/HI
291488
20 off
3 x 1
9
EVG-16/3X1PHAS/9MODUL/HI
291489
20 off
L L
17.8
L N L N L N
L1 L2 L3 L1 L2 L3
L1 L2 L3 N L1 L2 L3 N
L1 L2 L3 L1 L2 L1 L2
L3
L1 L2 L3 L1 L2 L3 L1 L2 L3 L1 L2
26.8
L
L
L N
L N
27
L1 L2 L3
L1 L2 L3
L1
L2
L3
EVG
HPL19026EN
