19/22 Circuit-breakers, fuses
Remote monitoring unit, remote switching modules
2010 CA08103002Z-EN
www.eaton.comRemotemonitoring unit, remote switchingmodules
Part no.
Article no.
Price
See price
list
Std. pack
Information relevant for export to North America
Remote monitoring unit
• GSM-based universal remote monitoring and control
through SMS
• Configuration and status monitoring through SMS
• Built-in modem monitoring and associated status
indication through front-mounted LEDs
• 2 changeover contacts
• 4 digital inputs, 2 relay outputs
–
Z-CC/2CO
119383
1 off
Accessories for remote monitoring unit
Power adaptor
24 V, 0.2 A
EASY200-POW
229424
1 off
Product Standards IEC/EN see Technical Data; UL 508;
CSA C22.2 No. 142-M1987; CSA C22.2
No. 213-M1987; CE marking
UL File No.
E135462
UL CCN
NRAQ
CSA File No.
012528
CSA Class No.
2252-01 + 2258-02
NA Certification
UL Listed, CSA certified
Degree of Protection IEC: IP20, UL/CSA Type: -
Temperature sensor
Z-CC/2CO-SE
119430
1 off
Part no.
Article no.
Price
See price
list
Std. pack
Remote switching modules
• IEC/EN 60669-2-2
• For remote switching and automatic restart of FAZ miniature circuit-breakers and FI residual-current devices up
to 80 A, except Type B
• Mechanically lockable and sealable
• LED indication of operational status and alarm status
• Mechanical switching capacity up to FAZ-...63 and up to FI-80..., except Type B (-XFSM)
• -25 °C/+40 °C
• Rated operating voltage 24 - 240 V AC, 24 - 48 V DC
• Terminal capacity 2 x 1.5 mm², 1 x 2.5 mm²; 0.4 Nm
• Mechanical/electrical lifespan 10 000 switching operations
• Power consumption 5 W
220 - 240 V AC
FAZ/FIP-XAWM
262514
1 off
48 V DC
FAZ/FIP-XDWM
274404
1 off
Remote test module
• External test module with test resistor for RCCB devices
• Version adapted for rated fault currents with stipulated “external” test button function
–
0.01 A
Z-FW/001
248297
4 off
0.03 A
Z-FW/003
248298
4 off
0.1 A
Z-FW/010
248299
4 off
0.3 A
Z-FW/030
248300
4 off
0.5 A
Z-FW/050
248301
4 off
Z-CC, FAZ/FIP-X, Z-FW
HPL19022EN
