19/38 Circuit-breakers, fuses
Miniature circuit-breakers for North America
2010 CA08103002Z-EN
www.eaton.comMiniaturecircuit-breakers forNorthAmerica
1 pole
2 pole
Rated operational
current
Interrupting
capacity
(SCCR)
Special approval for protection
of AWG 18 or AWG 16 to
NFPA70 (NEC) and NFPA 79
Part no.
Article no.
Price
See price
list
Std. pack
Part no.
Article no.
Price
See price
list
Std. pack
I
n
A
kA
Miniature circuit-breakers FAZ-RT
• With ring cable lug connection
• Characteristic D
• Switching capacity 15 kA IEC
0.5
10
AWG 18
FAZ-D0,5/1-RT
1)
102137
2 off
FAZ-D0.5/2-RT
1)
102217
1 off
1
10
AWG 18
FAZ-D1/1-RT
1)
102138
FAZ-D1/2-RT
1)
102218
1.5
10
AWG 18
FAZ-D0,5/1-RT
1)
102139
FAZ-D1.5/2-RT
1)
102219
2
10
AWG 18
FAZ-D2/1-RT
1)
102140
FAZ-D2/2-RT
1)
102220
3
10
AWG 18
FAZ-D3/1-RT
1)
102141
FAZ-D3/2-RT
1)
102221
4
10
AWG 18
FAZ-D4/1-RT
1)
102142
FAZ-D4/2-RT
1)
102222
5
10
AWG 18
FAZ-D5/1-RT
1)
102143
FAZ-D5/2-RT
1)
102223
6
10
AWG 18
FAZ-D6/1-RT
1)
102144
FAZ-D6/2-RT
1)
102224
7
10
AWG 18
FAZ-D7/1-RT
1)
102145
FAZ-D7/2-RT
1)
102225
8
10
AWG 16
FAZ-D8/1-RT
1)
102146
FAZ-D8/2-RT
1)
102226
10
10
AWG 16
FAZ-D10/1-RT
1)
102147
FAZ-D10/2-RT
1)
102227
13
10
–
FAZ-D13/1-RT
1)
102148
FAZ-D13/2-RT
1)
102228
15
14
–
FAZ-D15/1-RT
1)
102149
FAZ-D15/2-RT
1)
102229
16
14
–
FAZ-D16/1-RT
1)
102150
FAZ-D16/2-RT
1)
102230
20
14
–
FAZ-D20/1-RT
1)
102151
FAZ-D20/2-RT
1)
102231
25
14
–
FAZ-D25/1-RT
1)
102152
FAZ-D25/2-RT
1)
102232
30
10
–
FAZ-D30/1-RT
1)
102153
FAZ-D30/2-RT
1)
102233
32
10
–
FAZ-D32/1-RT
1)
102154
FAZ-D32/2-RT
1)
102234
35
10
–
FAZ-D35/1-RT
2)
102155
FAZ-D35/2-RT
2)
102235
40
10
–
FAZ-D40/1-RT
2)
102156
FAZ-D40/2-RT
2)
102236
k
1
2
1 3
2 4
FAZ-D...RT
