17/126 Circuit-breakers, switch-disconnectors
Main switch assembly kit
2010 CA08103002Z-EN
www.eaton.comMain switch assembly kit
Model
For use with
Part no.
Article no. when
ordered separately
Price
See
price
list
Std. pack
Information relevant for export to
North America
Main switch assembly kit with additional rotary handle
Main switch assembly kit with additional rotary handle for switching with opened
control panel door
Equipment supplied:
• Door coupling rotary handle
• Additional rotary handle on switch with “Deliberate Action” operation
• Extension shaft NZM…-XV6 for mounting depth 600 mm, NZM1/2-XV4 with NZM1
for mounting depth 400 mm
• External warning plate/designation label in German/English
• Black and yellow flash
For enhanced protection against direct contact on the incomer side,
IP2X protection against contact with a finger can be ordered￫Page 17/84
Other external warning plates/designation labels can be clipped on.
Degree of protection IP66/UL/CSA type 4X, 12
With black door coupling rotary handle
Lockable in 0 position
on handle with up to
3 padlocks, can also be
modified for the
I position. Lockable
door as additional
feature, locking facility
on circuit-breaker in
0 position.
IEC
NZM1(-4)
PN1(-4), N1(-4)
NZM1-XHB-DA
125956
1 off
Product Standards UL489;
CSA-C22.2
No. 5-09;
IEC60947,
CE marking
UL File No.
E140305
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification
UL Listed,
CSA certified
Degree of Protection IEC: IP66,
UL/CSA
Type 4X, 12
UL/CSA NZM1(-4)
PN1(-4), N(S)1(-4)
NZM1-XHB-DA-NA
125958
IEC
NZM2(-4)
PN2(-4), N(S)2(-4)
NZM2-XHB-DA
116895
UL/CSA NZM2(-4)
PN2(-4), N(S)2(-4)
NZM2-XHB-DA-NA
116897
IEC
NZM3(-4)
PN3(-4), N(S)3(-4)
NZM3-XHB-DA
118988
UL/CSA NZM3(-4)
PN3(-4), N(S)3(-4)
NZM3-XHB-DA-NA
119000
IEC
NZM4(-4)
PN4(-4), N(S)4(-4)
NZM4-XHB-DA
119002
UL/CSA NZM4(-4)
PN4(-4), N(S)4(-4)
NZM4-XHB-DA-NA
119004
With red door coupling rotary handle
For use of switch as emergency switching off device
Lockable in 0 position
on handle with up to
3 padlocks. With door
interlock and lockable
on switch in 0 position.
IEC
NZM1(-4)
PN1(-4), N1(-4)
NZM1-XHB-DAR
125957
1 off
Product Standards UL489;
CSA-C22.2
No. 5-09;
IEC60947,
CE marking
UL File No.
E140305
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification
UL Listed,
CSA certified
Degree of Protection IEC: IP66,
UL/CSA
Type 4X, 12
UL/CSA NZM1(-4)
PN1(-4), N(S)1(-4)
NZM1-XHB-DAR-NA
125959
IEC
NZM2(-4)
PN2(-4), N(S)2(-4)
NZM2-XHB-DAR
116896
UL/CSA NZM2(-4)
PN2(-4), N(S)2(-4)
NZM2-XHB-DAR-NA
116898
IEC
NZM3(-4)
PN3(-4), N(S)3(-4)
NZM3-XHB-DAR
118989
UL/CSA NZM3(-4)
PN3(-4), N(S)3(-4)
NZM3-XHB-DAR-NA
119001
IEC
NZM4(-4)
PN4(-4), N(S)4(-4)
NZM4-XHB-DAR
119003
UL/CSA NZM4(-4)
PN4(-4), N(S)4(-4)
NZM4-XHB-DAR-NA
119005
T
R
I
P
O
F
F
O
N
T
R
I
P
O
F
F
O
N
NZM...XS(R)M...
