Circuit-breakers, switch-disconnectors
Rotary handles with door interlock
2010 CA08103002Z-EN
www.eaton.com17/123
Rotaryhandleswithdoor interlock
For use with
Part no.
Article no. when
ordered
separately
Price
See
price
list
Std. pack
Notes
Information relevant for export to
North America
Rotary handles on switch with door interlock
Complete with rotary drive and insulating surround
Standard, black/grey
Lockable in 0 position
on handle with up to
3 padlocks, can also
be modified for the
I position. Also
available with door
interlock e.g. for MCC
service distribution.
NZM1(-4), PN1(-4),
N(S)1(-4)
NZM1-XDTV
260131
1 off
Door interlock
• In the ON position,
canbedefeatedfrom
the outside using a
1 mm pin
• Can
not
be defeated
in the locked OFF and
ON positions
• Door can be opened
in OFF
• Canonlybeswitched
ON when the door is
closed
Product Standards UL489;
CSA-C22.2
No. 5-09;
IEC60947,
CE marking
UL File No.
E140305
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification
UL Listed,
CSA certified
NZM2(-4), PN2(-4),
N(S)2(-4)
NZM2-XDTV
260133
Red-yellow for emergency switching off
Lockable in 0 position
on handle with up to
3 padlocks. Also
available with door
interlock e.g. for MCC
service distribution.
NZM1(-4), PN1(-4),
N(S)1(-4)
NZM1-XDTVR
260142
1 off
NZM2(-4), PN2(-4),
N(S)2(-4)
NZM2-XDTVR
260144
Rotary handles on switch with door interlock for
UL/CSA approved NA switches
Difference to normal IEC handles: Door opening only
possible with active rotation beyond the 0 position.
Complete with rotary drive and insulating surround
Standard, black/grey
Lockable in 0 position
on handle with up to
3 padlocks, can also
be modified for the
I position. Also
available with door
interlock e.g. for MCC
service distribution.
NZM1, N(S)1
NZM1-XDTV-NA
271453
1 off
Door interlock
• In the ON position,
canbedefeatedfrom
the outside using a
1 mm pin
• Can
not
be defeated
in the locked OFF and
ON positions
• Door opening only
possible with active
rotation beyond the
0 position.
• Canonlybeswitched
ON when the door is
closed
• Cannot be combined
with mechanical
interlock
Product Standards UL489;
CSA-C22.2
No. 5-09;
IEC60947,
CE marking
UL File No.
E140305
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification
UL Listed,
CSA certified
NZM2, N(S)2
NZM2-XDTV-NA
271454
Red-yellow for emergency switching off
Lockable in 0 position
on handle with up to
3 padlocks. Also
available with door
interlock e.g. for MCC
service distribution.
NZM1, N(S)1
NZM1-XDTVR-NA
271455
1 off
NZM2, N(S)2
NZM2-XDTVR-NA
271456
Notes
Circuit-breaker can also be installed in a lying position 90° left/right, with the handle still in the same position.
NZM...-XDTV
