Eaton Industrial Switchgear - XEnergy XPole Energy distribution, switching and protection

217 / 543

2010 CA08103002Z-EN
Circuit-breakers, switch-disconnectors
Door coupling rotary handles for North America
For maximum shaft length
60 mm
Extremely narrow fittings
Part no.
Article no.
Price
See
price list
Std. pack Notes Part no.
Article no.
Price
See
price list
Std. pack Notes Information relevant for
export to North America
– – – – Product Standards
UL489;
CSA-C22.2
No. 5-09;
IEC60947,
CE marking
UL File No. E140305
UL CCN DIHS
CSA File No. 022086
CSA Class No.1437-01
NA Certification
UL Listed,
CSA certified
Degree of Protection
IEC: IP66, UL/
CSAType4X,
12
– –
– –
– –
NZM1-XTVDV-
60-NA
100667
1 off Door interlock
• Can not be defeated in
the locked OFF position.
• Door opening possible
with active rotation
beyond the 0 position.
Can be defeated from
the outside using a
screwdriver.
• Cannot be combined
with mechanical
interlock
• External warning plate/
designation label can
be clipped on.
NZM…-XTVDV-60-NA
• For a maximum shaft
length of 60 mm
• Without shaft support
• Cannot be combined
with additional handle
NZM...-XDZ
• External warning plate/
designation label can
be clipped on.
NZM1-XTVDV-
0-NA
100675
1 off Door interlock
• Can not be defeated in
the locked OFF position.
• Door opening possible
with active rotation
beyond the 0 position.
Can be defeated from
the outside using a
screwdriver.
• Cannot be combined
with mechanical
interlock
• External warning plate/
designation label can
be clipped on.
NZM…-XTVDV-0-NA
• For extremely narrow
fittings
• With special short
extension shaft
• Cannot be combined
with additional handle
NZM...-XDZ
• External warning plate/
designation label can
be clipped on.
NZM2-XTVDV-
60-NA
100668
NZM2-XTVDV-
0-NA
100676
NZM3-XTVDV-
60-NA
100669
NZM3-XTVDV-
0-NA
100677
NZM4-XTVDV-
60-NA
100670
NZM4-XTVDV-
0-NA
100678
NZM1-
XTVDVR-60-
NA
100671
1 off Door interlock
• Can not be defeated in
the locked OFF position.
• Door opening with
active rotation beyond
the 0 position.
• Cannot be combined
with mechanical
interlock
• External warning plate/
designation label can
be clipped on.
NZM…-XTVDVR-60-NA
• For a maximum shaft
length of 60 mm
• Without shaft support
• Cannot be combined
with additional handle
NZM...-XDZ
• External warning plate/
designation label can
be clipped on.
NZM1-
XTVDVR-0-NA
100679
1 off Door interlock
• Can not be defeated in
the locked OFF position.
• Door opening with
active rotation beyond
the 0 position.
• Cannot be combined
with mechanical
interlock
• External warning plate/
designation label can
be clipped on.
NZM…-XTVDVR-0-NA
• For extremely narrow
fittings
• With special short
extension shaft
• Cannot be combined
with additional handle
NZM...-XDZ
• External warning plate/
designation label can
be clipped on.
Product Standards
UL489;
CSA-C22.2
No. 5-09;
IEC60947,
CE marking
UL File No. E140305
UL CCN DIHS
CSA File No. 022086
CSA Class No.1437-01
NA Certification
UL Listed,
CSA
certified
Degree of Protection
IEC: IP66, UL/
CSAType4X,
12
NZM2-
XTVDVR-60-
NA
100672
NZM2-
XTVDVR-0-NA
100680
NZM3-
XTVDVR-60-
NA
100673
NZM3-
XTVDVR-0-NA
100681
NZM4-
XTVDVR-60-
NA
100674
NZM4-
XTVDVR-0-NA
100682
– – – – UL/CSA certification not
required
– –
– –
– –
17/121
NZM1, NZM2, NZM3, NZM4 HPL17121EN
