www.eaton.comCircuit-breakers, switch-disconnectors
Door coupling rotary handles
For maximum shaft
length 60 mm
Extremely narrow
fittings
Part no.
Article no.
when
ordered
separately
Price
Seeprice
list
Std. pack
Notes
Part no.
Article no.
when
ordered
separately
Price
Seeprice
list
Std. pack
Notes
Information relevant for export
to North America
NZM1-
XTVD-60
271504
1 off
Door interlock
• Can
not
be defeated in
the locked OFF and ON
positions
• Can be modified such
that it can be defeated
from the outside using
a screwdriver, when it
is in the unlocked ON
position.
• Door can be opened in
OFF
NZM…-XTVD(V)-60
• For maximum shaft
length 60 mm
• Without shaft support
• Cannot be combined
with additional handle
NZM...-XDZ
• External warning
plate/designation label
can be clipped on.
NZM1-
XTVD-0
279392
1 off
Door interlock
• Can
not
be defeated in
the locked OFF and ON
positions
• Can be modified such
that it can be defeated
from the outside using a
screwdriver, when it is
in the unlocked ON
position.
• Door can be opened in
OFF
NZM…-XTVD(V)-0
• For extremely narrow
fittings
• With special short
extension shaft
• Cannot be combined
with additional handle
NZM...-XDZ
• External warning plate/
designation label can
be clipped on.
Product Standards
UL489;
CSA-C22.2
No. 5-09;
IEC60947,
CE marking
UL File No.
E140305
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification UL Listed,
CSA certified
Degree of Protection
IEC: IP66,
UL/CSA
Type 4X, 12
NZM2-
XTVD-60
271505
NZM2-
XTVD-0
279393
NZM3-
XTVD-60
271506
NZM3-
XTVD-0
279394
NZM4-
XTVD-60
271507
NZM4-
XTVD-0
279395
NZM1-
XTVDV-60
271508
NZM1-
XTVDV-0
279396
NZM2-
XTVDV-60
271509
NZM2-
XTVDV-0
279397
NZM3-
XTVDV-60
271510
NZM3-
XTVDV-0
279398
NZM4-
XTVDV-60
271511
NZM4-
XTVDV-0
279399
NZM1-
XTVDVR-60
271512
1 off
Door interlock
• Can
not
be defeated in
the locked OFF position.
• Can be modified such
that it can be defeated
from the outside using
a screwdriver, when it
is in the unlocked ON
position.
• Door can be opened in
OFF
NZM…-XTVDVR-60
• For maximum shaft
length 60 mm
• Without shaft support
• Cannot be combined
with additional handle
NZM...-XDZ
• External warning
plate/designation label
can be clipped on.
NZM1-
XTVDVR-0
279400
1 off
Door interlock
• Can
not
be defeated in
the locked OFF position.
• Can be modified such
that it can be defeated
from the outside using a
screwdriver, when it is
in the unlocked ON
position.
• Door can be opened in
OFF
NZM…-XTVDVR-0
• For extremely narrow
fittings
• With special short
extension shaft
• Cannot be combined
with additional handle
NZM...-XDZ
• External warning plate/
designation label can
be clipped on.
NZM2-
XTVDVR-60
271513
NZM2-
XTVDVR-0
279401
NZM3-
XTVDVR-60
271514
NZM3-
XTVDVR-0
279402
NZM4-
XTVDVR-60
271515
NZM4-
XTVDVR-0
279403
–
–
–
–
UL/CSA certification not required
–
–
–
–
–
–
17/119
NZM1, NZM2, NZM3, NZM4
