17/106 Circuit-breakers, switch-disconnectors
Auxiliary contacts with screw terminals/spring-cage terminal
2010 CA08103002Z-EN
www.eaton.comAuxiliarycontactswith screw terminals/spring-cage terminal
For use with
Contact configuration:
= safety function by positive
opening according to
IEC/EN 60947‐5‐1
Contact
sequences
Part no.
Article no.
when ordered
separately
Price
See price
list
Std. pack
N/O = normally
open contact
NC = normally
closed contact
Auxiliary contacts
Standard auxiliary contacts (HIN)
1)
Switches with the main contacts. Used for indicating and interlocking tasks.
Single contact
NZM1(-4), 2(-4), 3(-4), 4(-4)
PN1(-4), 2(-4), 3(-4)
N(S)1(-4), 2(-4), 3(-4), 4(-4)
1 N/O
M22-K10
216376
20 off
1 NC
M22-K01
216378
Double contact NZM1(-4), 2(-4), 3(-4), 4(-4)
PN1(-4), 2(-4), 3(-4)
N(S)1(-4), 2(-4), 3(-4), 4(-4)
1 N/O
1 NC
2 NC
2 N/O
Early-make auxiliary contact
2)
For interlocking and load shedding circuits, as well as for early make of the undervoltage
release in main switch/emergency switching off applications
With clamp
terminal on left
switch side.
NZM1(-4)
PN1(-4)
N(S)1(-4)
2 N/O
–
NZM1-XHIV
259426
1 off
With clamp
terminal on
right switch
side.
2 N/O
–
NZM1-XHIVR
292195
With 3 m
connection
cable instead
of screw
connection.
2 N/O
–
NZM1-XHIVL
259432
–
NZM2(-4), 3(-4)
PN2(-4), 3(-4)
N(S)2(-4), 3(-4)
2 N/O
–
NZM2/3-XHIV
259430
NZM4(-4)
N(S)4(-4)
2 N/O
–
NZM4-XHIV
266172
Trip indicating auxiliary contact (HIA), (HIAFI)
1)
General trip indication “+”, when tripped by shunt release, overload release, short-circuit release or earth-fault release
due to fault current.
Single contact
NZM1(-4), 2(-4), 3(-4), 4(-4)
PN1(-4), 2(-4), 3(-4)
N(S)1(-4), 2(-4), 3(-4), 4(-4)
1 N/O
M22-K10
216376
20 off
1 NC
M22-K01
216378
20 off
Double contact NZM1(-4), 2(-4), 3(-4), 4(-4)
PN1(-4), 2(-4), 3(-4)
N(S)1(-4), 2(-4), 3(-4), 4(-4)
1 N/O
1 NC
2 NC
2 N/O
Information relevant for
export to North America
1)
Product Standards IEC/EN 60947-5; UL 508; CSA-C22.2
No. 14-05; CSA-C22.2 No. 94-91; CE marking
UL File No.
E29184
UL CCN
NKCR
CSA File No.
012528
CSA Class No.
3211-03
NA Certification UL Listed, CSA certified
Degree of Protection UL/CSA Part no.:
1.X3
1.X4
1.X1
1.X2
1.X3
1.X4
1.X1
1.X2
1.X1
1.X2
1.X1
1.X2
1.X3
1.X4
1.X3
1.X4
3.13 3.23
3.14 3.24
3.13 3.23
3.14 3.24
3.13 3.23
3.14 3.24
3.13 3.23
3.14 3.24
3.13 3.23
3.14 3.24
1.X3
1.X4
1.X1
1.X2
1.X3
1.X4
1.X1
1.X2
1.X1
1.X2
1.X1
1.X2
1.X3
1.X4
1.X3
1.X4
NZM1, M22-...
