www.eaton.comCircuit-breakers, switch-disconnectors
Terminals
Part no.
Article no. when
ordered separately
Price
See price
list
Std. pack
Notes
Information relevant for export to
North America
NZM3/4-XSTS
266797
1 off
Contains parts for two terminal locations located at top or bottom
for 3 or 4 pole circuit-breakers.
Included as standard with tunnel terminal.
Degree of protection IP1X
Height or thickness of the control circuit terminals:
NZM-XSTS = 2 mm
Product Standards UL489;CSA-C22.2No. 5-09;
IEC60947, CE marking
UL File No.
E140305
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1437-01
NA Certification
UL Listed, CSA certified
Suitable for
Refer to main component
information
NZM4-XKSA
266846
1 off
Contains parts for a terminal located at top or bottom for 3 or 4 pole
switches.
Contact protection where cable lugs, bars, flat cable terminals or
tunnel terminals are used.
Included in set with tunnel terminals.
When using insulated conductor material, degree of protection
IP1X.
Product Standards UL489;CSA-C22.2No. 5-09;
IEC60947, CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1432-01
NA Certification
UL Listed, CSA certified
Suitable for
Refer to main component
information
NZM4-4-XKSA
266847
1 off
NZM4-XKSAV
119876
1 off
Contains parts for a terminal located at top or bottom for
3 pole circuit-breakers.
Insulation protection/protection against direct contact for
connection of cable lugs or bars to connection width extension.
When using insulated conductor material, degree of protection
IP2X.
UL/CSA certification not required
NZM4-XISP
119866
1 off
Contains parts for a terminal located at top or bottom for 3 or 4 pole
switches.
Insulation protection when minimum distance frommounting plate
not observed.
Included with the connection width extension.
Product Standards UL489;CSA-C22.2No. 5-09;
IEC60947, CE marking
NA Certification
Request filed for UL and
CSA
Suitable for
Refer to main component
information
NZM4-4-XISP
119867
1 off
NZM4-XKSFA
292193
1 off
Contains parts for a terminal located at top or bottom for 3 or 4 pole
switches.
Increased contact protection with connection of insulated bars or
flat band.
UL/CSA certification not required
NZM4-4-XKSFA
292194
1 off
NZM4-XKP
281595
1 set
Contains parts for a terminal located at top or bottom for 3 or 4 pole
switches.
Included with the connection width extension.
Cannot be combined with tunnel terminal NZM4(-4)-XKA or rear
connection NZM4-XKR.
Insulation protection where cable lugs, bars, module plates or
tunnel terminals are used.
Product Standards UL489;CSA-C22.2No. 5-09;
IEC60947, CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1432-01
NA Certification
UL Listed, CSA certified
Suitable for
Refer to main component
information
NZM4-4-XKP
281596
1 set
NZM3-XKS185
260040
3 off
The part no. contains a cable lug for 3 or 4 pole switch.
Special cable lug, narrow style
NZM3-XKS240
260041
17/103
NZM4
