17/102 Circuit-breakers, switch-disconnectors
Terminals
2010 CA08103002Z-EN
Terminals
Number of poles For use with Terminal capacity
Connection Terminal capacity AWG/kcmil
mm²
Control cable terminals
3 and 4 pole NZM3(-4),
PN3,
N(S)3(-4)
Screw terminals 1 x 0.75-2.5
2 x 0.75-1.5
1 x 18-14
2 x 18-16
Cover
3 pole NZM4,
N(S)4
4 pole NZM4-4,
N4-4
Cover size
For connection width extension
3 pole NZM4, N(S)4
+ NZM4-XKV95(KB)
Insulation plate
3 pole NZM4, N(S)4
+ NZM4-XKV…
4 pole NZM4(-4), N(S)4(-4)
+ NZM4-4-XKV…
Terminal covers, knockout
3 pole NZM4,
N(S)4
4 pole NZM4-4,
N4-4
Phase isolators
3 pole NZM4
N(S)4
4 pole NZM4-4, N4-4
Cable lug
Not UL/CSA approved
When using cable lugs without NZM3(-4)-XKSA cover, they must be insulated.
3 and 4 pole NZM4(-4), N(S)4(-4) 185 mm2
240 mm2
NZM4 HPL17102EN
