Circuit-breakers, switch-disconnectors
Plug-in units, withdrawable units
2010 CA08103002Z-EN
www.eaton.com17/105
Plug-inunits,withdrawableunits
For use with
Number of poles
Part no.
Article no.
Price
SeePrice
List
Std.
pack
Notes
Plug-in units
For circuit-breakers NZM and switch-disconnectors N
Not UL/CSA approved
Not for U
e
> 690 V
B = box terminals
S = screw terminals
For further terminal types
see accessories
Plug-in socket
Completion
through switches
with plug-in
insert
NZM...-SVE...
NZM1
N1
3 pole
NZM1-XSVS
109777
B 1 off
I
nmax.
at:
20°C: 125 A (NZM1)
70°C: 100 A (NZM1)
Mounting position: vertical, 90° right, 90° left
Order control circuit plug unit separately!
NZM2
N2
3 pole
NZM2-XSVS
266699
S 1 off
I
nmax.
at:
20°C: 250 A
40°C: 230 A (NZM…2-…)
250 A (NZM…2-E…)
Mounting position: vertical, 90° right, 90° left
Order control circuit plug unit separately!
NZM2-4
N2-4
4 pole
NZM2-4-XSVS
266700
S 1 off
Control circuit plug unit
–
NZM1, N1
NZM2(-4)
N2(-4)
For auxiliary
contact,
shunt/over-
voltage release
NZM2-XSVHI
266705
– 1 off
10 terminals
–
NZM2(-4)
N2(-4)
For remote
operator
NZM2-XSVR
266706
– 1 off
For use
with
Number
of poles
Part no. suffix
Article no. for
orderwithbasic
device
Price
SeePrice
List
Std.
pack
Part no.
Article no. for
separate order
Price
See Price
List
Std.
pack
Notes
Withdrawable unit
For circuit-breakers NZM and switch-
disconnectors N
Not UL/CSA approved
Not for U
e
> 690 V
Socket base
For switches with withdrawable carrier.
Also for reserved compartments.
NZM3
N3
3 pole –
NZM3-XAVS
266711
S 1 off
I
nmax.
at:
20 °C: 605 A (NZM3), 1600 A (NZM4)
40 °C: 550 A (NZM3), 1500 A (NZM4)
Mounting position:
NZM3: vertical, 90° left
NZM4: vertical
3 positions:
Connected, test, disconnected
Position indication is mechanical
with pointers.
Additional electrical indication with
auxiliary contacts possible.
One N/O or NC contact M22-(C)K01
or M22-(C)K10 each per position.
Alternatively also double contacts
M22-CK...
Complete with control circuit plug
unit.
All auxiliary contact (HIA, HIN, HIV)
and shunt release connections to
the control circuit plug unit are
already present.
Maximum configuration: 3 contacts
HIN, 2 contacts HIA, 2 contacts HIV
Cannot be combinedwith adapterset
NZM4/NZM14(NZM4‐XSAS14‐…)or
N(ZM)4/N(ZM)12.
NZM3-4
N3-4
4 pole –
NZM3-4-XAVS
266712
S 1 off
NZM4
N4
3 pole –
NZM4-XAVS
266713
S 1 off
NZM4-4
N4-4
4 pole –
NZM4-4-XAVS
266714
S 1 off
Withdrawable carrier
Suitable for socket base
Only in combination with switch
NZM4
N4
3 pole
+NZM4-XAVE
266717
1 off
–
–
NZM4-4
N4-4
4 pole
+NZM4-4-XAVE
266718
1 off
–
–
NZM1, NZM2, NZM3, NZM4
