www.eaton.comCircuit-breakers, switch-disconnectors
Terminals
Part no.
Article no. when
ordered separately
Price
See price
list
Std. pack
Notes
Information relevant for export to North America
NZM4-XKV95
281591
1 set
Contains parts for a terminal located at top or bottom for
3 or 4 pole switches.
Five-hole fitting, for example, for up to nine cable lugs per phase.
Can be fitted to circuit-breaker with screw terminal.
Phase isolator supplied.
Distance between pole centres with NZM4(-4)-XKV95: 95 mm
Installation conditions for current transformer up to 130 mmwidth
with 80 mm bar width.
Distance between pole centers with NZM4-XKV110: 107.5 mm
Installation conditions for current transformer up to 135 mmwidth
with 80 mm bar width.
Distance between pole centers with NZM4-4-XKV120: 122 mm
Installation conditions for current transformer up to 164 mmwidth
with 80 mm bar width.
4 mm holes predrilled for control cable terminal.
NZM4-XKV95 contains hole for large cover NZM4-XKSAV.
Product Standards UL489;CSA-C22.2No. 5-09;
IEC60947, CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1432-01
NA Certification
UL Listed, CSA certified
Suitable for
Refer to main component
information
NZM4-XKV110
281593
NZM4-4-XKV95
281592
1 set
–
NZM4-4-XKV120
281594
–
NZM4-XKV95-2KB
119861
1 set
Contains parts for a terminal located at top or bottom for
3 pole circuit-breakers.
Threaded stud for cable lugs up to 4 × 300 mm
2
Can be fitted to circuit-breaker with screw terminal.
Phase isolator, insulation plate and 2 control circuit terminals
supplied.
Product Standards UL489;CSA-C22.2No. 5-09;
IEC60947, CE marking
UL File No.
E31593
UL CCN
DIHS
CSA File No.
022086
CSA Class No.
1432-01
NA Certification
UL Listed, CSA certified
Suitable for
Refer to main component
information
